HEAVY-DUTY TRUCK SERVICE TOOLS
TOOLS Hose Clamp Sockets 204FIHC FIHC140 FIHCM8 Set 204FIHC

Contains:
HAND Drive Size, inches Stock No. 10 mm 12.9 mm 17.2 mm 57.1 mm Set shown includes storage tray.
A
B
D
C
7/16
3/8
2-3/4ʺ
11/16ʺ
FIHC140
21/32ʺ
2-1/4ʺ
•
3/8
2-1/4ʺ
2-3/4ʺ
3/4ʺ
FIHC160
1/2ʺ
3/4ʺ
•
3/8
69.8 mm
8 mm
FIHCM8
•
69.8 mm
15.9 mm
17.2 mm
3/8
57.1 mm
FIHCM10
•
Torque Adaptor
SRD35 Diesel Head Bolt Torque Adaptor
GENERAL
• Eliminates the need to remove the truck/van cab from the chassis to access the
rear head bolts, saving the technician time and preventing damage to the rear
heat shield
• When coupled with an SM18, 18 mm socket, can access all of the head bolts,
eliminating the need to change tools or remove the adaptor during the job
SRD35
• Use of 3/4ʺ drive ratchet/torque wrench transmits the high-torque necessary to
loosen and tighten head bolts, with less strain on the technician
• Eliminates the need to remove the evaporator housing, saving two hours of time
and the additional cost of refrigerant added during air conditioning recharging
• 3/4ʺ square drive, 3-1/2ʺ center-to-center length, 4-7/8ʺ overall length
SRDM624 Torque Adaptor
®
• Services the rear brake caliper mounting bracket assembly on 2007 Ford
F-450/F-550 trucks
• Tool fits between the bracket bolt and frame to allow the use of a torque wrench
SRDM624
to properly torque the bracket bolts
• 1/2ʺ square drive, 12-point, 24 mm, 6ʺ center-to-center length, 7-7/32ʺ long
Slack Adjusters
BSA916 ‡ Slack Adjuster Wrench
• For brake service and slack adjuster installation on heavy-duty trucks equipped
®
with Bendix automatic slack adjusters
BSA916
• Used to turn the manual adjuster hex
• Extra-deep 9/16ʺ hex allows reach to recessed adjusters
• 14-1/2ʺ overall length helps to overcome the anti-reverse mechanism
• Turn over to reverse
• Includes a protective vinyl boot
HSA716 ‡ Slack Adjuster Wrench
• For brake service and slack adjuster installation on heavy-duty trucks equipped
®
with Haldex automatic slack adjusters
HSA716 • Used to turn the manual adjuster hex
• Extra-deep 7/16ʺ hex allows reach to recessed adjusters
• 14-5/8ʺ overall length helps to overcome the anti-reverse mechanism
• Turn over to reverse
• Protective vinyl boot helps to keep contaminants out of the ratchet mechanism
for extended tool life
492
Snapon.com 1.877.762.7664
