AVIATION: SPECIALTY SERVICE TOOLS

Torque Adaptors, mm (1/4ʺ Drive)
TRDHM6 1/4ʺ Drive 12-Point Metric TRDHM7 1/4ʺ Drive 12-Point Metric TRDHM8 1/4ʺ Drive 12-Point Metric
6 mm Torque Adaptor 7 mm Torque Adaptor 8 mm Torque Adaptor
• Manufactured from special • Manufactured from special • Manufactured from special
alloy steel alloy steel alloy steel
• Precision forged and heat treated • Precision forged and heat treated • Precision forged and heat treated
for optimum strength and durability for optimum strength and durability for optimum strength and durability GENERAL
• 12-point double hex allows the • 12-point double hex allows the • 12-point double hex allows the
socket to engage single hex socket to engage single hex socket to engage single hex
fastener every 30° rather than every fastener every 30° rather than every fastener every 30° rather than every
60°, allowing for better access in 60°, allowing for better access in 60°, allowing for better access in
restricted areas restricted areas restricted areas
• 1ʺ center-to-center length on • 1ʺ center-to-center length on • 1ʺ center-to-center length on
adaptor for easy torque calculations adaptor for easy torque calculations adaptor for easy torque calculations
• Design features radius edges that • Design features radius edges that • Design features radius edges that
resist damage/nicks resist damage/nicks resist damage/nicks
Stock No. A B C D E
6 TRDHM6 9.5 11.9 6.6 6.6 25.4
7 TRDHM7 9.5 11.9 6.6 6.6 25.4
8 TRDHM8 9.5 11.9 6.6 6.6 25.4
• For applications involving AS350/355 Airbus helicopters (formerly Eurocopter) known as A-star and Twin-Star
®
helicopters in North America
• Used attached to a torque wrench on a hard-to-reach fastener HAND

Hose Clamp Socket TRDHM6
AHCS1 Aircraft Hose Clamp Socket
• Use on hose clamps found on • Competitive sockets only work on one
®
®
Lycoming , TCM (Continental ) and size and have a rubber O-ring that can
®
other engines found on Cessna , Piper cause an FOD issue
®
®
and Beechcraft aircraft • Manufactured from special alloy steel,
• Slotted socket is for removing and precision forged and heat treated for
installing the three different size thumb optimum strength and durability AHCS1
knobs found on aircraft hose clamps • 1/4ʺ square drive
True Flush: Blades cut stranded wire ends and zip tie ends flat, TOOLS
allowing protruding ends to be trimmed flush
Semi-Flush: Ground blades cut slightly pointed wire ends and 84CFCTA
can be used where an exact flush cut is not required
Shear Cut: Ground blades (on standard cutters) are designed for
general cutting with less hand pressure and extended blade life
86ACFCT
Cushion Throat Cutters
• Urethane insert in jaws captures clipped material, reducing the likelihood of work
environment contamination
• Retention of wire clippings enhances worker safety by preventing projectile material from
being scattered throughout the worksite P87150CT
• Handles are designed for comfort and deliver the leverage needed to tackle the most
demanding jobs
• Quality forged steel ensures tools will provide years of service
• Fluorescent urethane formula helps reduce the potential of leaving the tool behind—just
shine a UV light on the head of the cutter to activate its illuminating effect
Dimension B, Dimension C, 786CFCT
Dimension A,
Stock No. Description Jaw Length, Overall Length,
Handle Type
inches inches
84CFCTA Cushion Throat Diagonal Cutter Bowed 3/8 4-3/4
86ACFCT Cushion Throat Diagonal Cutter Bowed 3/4 6-5/16
P87150CT Cushion Throat 5ʺ Oval Cutter—True Flush Cut Bowed 17/32 5-3/16 87ACFCT
786CFCT 6ʺ Diagonal Flush-Cut Cutter with Cushion Throat Bowed 3/4 6-5/18
87ACFCT 7ʺ VectorEdge Diagonal Cutter Bowed 13/16 7-3/8
388ACFCT 8ʺ High-Leverage Cushion Throat Diagonal Cutters Bowed 1-1/16 8-5/16

388ACFCT
• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers 497
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
