HEAVY-DUTY TRUCK SERVICE TOOLS

Valve Adjusters
S6205 Valve Adjuster Socket • Unique handle pivots from one side to
• See-through window in the 14 mm socket the other so the window is always visible S6205
allows the technician to see the position • Made from heat-treated 4140 steel, the
of the 5 mm hex blade tool is strong enough to handle the high
• Faster valve adjustment time breaking torque required after long
• Sized for low clearance service intervals
• Made from heat-treated steel • Multi-functional design frees up one GENERAL
• Soft grip handle hand for feeler gauge operation
• Applications include 2002-later VAT940 Diesel Valve Adjustment Tool S6206
Mercedes-Benz 900 series diesel 15 mm/Flat
®
engines and 2002-later trucks and buses • Two-in-one tool features a window in the
S6206 Valve Adjuster Socket socket allowing the technician to see the
• See-through window in the 17 mm socket position of the screwdriver blade holding
allows the technician to see the position the adjustment screw as it is tightened
of the 6 mm hex blade • Unique handle pivots from one side to
• Faster valve adjustment time the other so the window is always visible
• Sized for low clearance • Made from heat-treated 4140 steel, the VAT930
• Made from heat-treated steel tool is strong enough to handle the high
• Soft grip handle breaking torque required after long
• Applications include 2002-later service intervals
®
Mercedes-Benz 4000 series diesel • Multi-functional tool design frees up one VAT940
engines and 2002-later trucks and buses hand for feeler gauge operation
VAT930 Diesel Valve Adjustment Tool YA8880-3 Wire Handle with Grip
15 mm/7 mm • Handle with slip cover—clips into the tool HAND
• Two-in-one tool features a window in and pivots from one side to the other so
the socket allowing the technician to the socket “window” is always visible
see the position of the nut driver holding
the adjustment screw as the jam nut
is tightened
MOTORCYCLE SERVICE TOOLS

Special Application
S9704RHS 3/8ʺ Drive 6-Point SAE S9724RHS 3/8ʺ Drive 6-Point SAE
13/16ʺ Flank Drive Low-Profile Spark 5/8ʺ Flank Drive Low-Profile Spark
®
®
Plug Socket Plug Socket TOOLS
• Spark plug extends through the socket • Spark plug extends through the socket
for access in tight quarters for access in tight quarters
• Patented tapered hex design securely • Patented tapered hex design securely S9704RHS
retains the spark plug in the socket retains the spark plug in the socket
without a rubber insert or magnet without a rubber insert or magnet
• Patented diamond wedge design with six • Patented diamond wedge design with
wedges equally align spark plug in the six wedges equally aligns the spark
center to avoid damage to the porcelain plug in the center to avoid damage
• Spark plug is easily disengaged from the to the porcelain
socket by applying gentle side pressure • Spark plug is easily disengaged from the
to break the contact socket by applying gentle side pressure
• Low-profile socket easily reaches spark to break the contact S9724RHS
plugs without interference from custom • Low-profile socket easily reaches spark
exhausts or chassis plugs without interference from custom
• Side through hole for secure exhausts or chassis
®
®
extension retention • Snap-on sockets using the Flank Drive
®
• Snap-on sockets using the Flank Drive wrenching system grip the fastener on
®
wrenching system grip the fastener on the flanks/flats, delivering 15–25% more
the flanks/flats, delivering 15–25% more turning power
turning power • Manufactured from the highest quality
• Manufactured from the highest quality proprietary steel, providing optimum
proprietary steel, providing optimum strength and durability
strength and durability • Nickel-chrome plating helps protect
• Nickel-chrome plating helps protect against corrosion and makes it easy to
against corrosion and makes it easy to wipe clean
wipe clean • Spark plug socket is cold formed for
• Spark plug socket is cold-formed for extended tool life
extended tool life
• Knurled surface for finger tightening
and removal
• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers 493
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
