MOTORCYCLE SERVICE TOOLS
TOOLS HD6529 HD6529 ‡ Ratcheting Hex Wrench (Blue-Point ) ® ®
Adjusting Tools
®
• Reversible ratchet lever is conveniently located for one-hand operation
• 3/16ʺ hex bit is easily replaced if damaged
• Low-profile design for extra clearance between the frame and engine
• Comfortable rubber grip will not scratch chrome
• 9-3/4ʺ overall length for additional reach
• 1/4ʺ hex drive, 3/16ʺ hex bit for Harley-Davidson Evolution motor rocker box
cover bolts
HFTLRT Fuel Tank Lock Ring Tool Harley-Davidson
• Allows access to the fuel filter and fuel pump as the lock ring is connected
to the pump ®
HAND NBAT1 • For neck bearing adjustment on Harley-Davidson motorcycles
• Made of durable ABS plastic (competitive products are metal and can scratch the
HFTLRT
painted surface of the motorcycle)
NBAT1 ‡ Neck Bearing Adjustment Tool
®
• Easily maneuvers between the triple clamp and frame
• Fits into the star adjustment nut, allowing technician to adjust the neck
bearing play
• Tapered end allows easy access to the neck bearing adjusting star
• Screwdriver-style handle offers a comfortable grip
• 18-1/2ʺ overall length
• Neck bearing adjustment is usually checked at the following service intervals:
1,000, 5,000, 15,000 and 25,000 miles or annually
GENERAL
Fuel Tank Cover
KAC1224TCA Motorcycle Gas Tank Cover
®
®
®
• Fits Harley-Davidson Dyna , Softail and Touring models
®
®
®
®
• Fits various models of Yamaha , Victory , Triumph and Kawasaki motorcycles,
plus many more
KAC1224TCA • Non-marring cover uses a non-abrasive inner liner that will not slide off
Motorcycle Service Equipment
EEPV503 ‡ Motorcycle Compression Gauge Set
• Tests motorcycles and recreational vehicles with hard-to-access spark plug ports
• Gauge assembly includes a 2-3/4ʺ dia. gauge and 18ʺ flexible hose with a
quick coupler
• Includes EEPV5G10L, EEPV5G12L and EEPV5G14L
• Technical Support: 1-855-779-8880
EEPV503
General Service Tools
CPT110A 3/8ʺ Drive 6-Point Metric 17 mm VW Transmission Drain Plug Socket
®
®
• For use on VW transmission drain plugs
®
®
• Additional applications include removing the front wheels on Triumph Daytona
®
and America motorcycles
®
YA173B ‡ Clip-On-Style Angled Air Chuck (Blue-Point )
YA173B
• 1/4ʺ-18 female NPT
• Spring-loaded, trigger-operated valve stem clip
• Maximum operating pressure is 200 PSI
• For use with air lines only—do not use on inflators
MT125A Self-Powered Timing Light (Blue-Point )
®
• Self-powered timing light features a single 6ʹ inductive pick-up
• Quick attachment to spark plug wires on motorcycles, marine motors, snowmobiles,
jet skis, small engines and other equipment that do not have easy access to a
battery power source
• Can be used for automotive applications
MT125A • On/Off switch is located within thumb’s reach
• Maximum 2,000 RPM
SGSR104AR * 4 pc Soft Grip Seal Removal Tool Set Red
• For use on transmissions, heater and vacuum hoses, oil pump drive shaft seals,
injectors and fuel rail O-rings, inner tie-rod rack boot and CV boot removal, fork
®
seals, and caliper dust boot assemblies on Harley-Davidson and other motorcycles,
and steering racks and pumps Colors Available
• SGSR1AR–SGSR4AR (4 pc) in a storage tray
SGSR104AR
494 Red Orange Green
* R O G
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
Snapon.com 1.877.762.7664
