OIL AND GAS SERVICE TOOLS

Shallow, Single Square Impact Sockets, inches
• This “end effector” socket is used in the manufacturing of subsea and surface IM748BC1.5
wellhead equipment in the oil and gas industries
Stock No. Square Drive, inches A B C D E GENERAL
1 IM632BC1.5 3/4 2-1/8 1-3/4 — 2-1/4 3/4
1-1/2 IM748BC1.5 1 2-7/8 2-3/8 1-5/8 3-1/2 7/8
1.66 IM753.1BC1.5 1 1-15/16 2-3/8 — 3-1/2 1-1/16
1 IM732BC1.5 1 2-1/8 2-1/8 — 2-3/4 3/4

APW10VLV ATSK3621 GADW8VLV GADW10VLV

Specialty Service Tools
APW10VLV Valve Persuader Wrench GADW8VLV 8-1/2ʺ Adjustable Valve GADW10VLV 10ʺ Adjustable Valve HAND
• Refinery wrench used in oil and gas Persuader Wrench Persuader Wrench
downstream facilities • Two tools combined into one • Two tools combined into one
• Great universal multi-tool for convenient operator’s tool that convenient operator’s tool that
numerous daily applications, can be used wherever valves are can be used wherever valves are
including 4 and 6ʺ quick turns to adjusted for flow and pressure adjusted for flow and pressure
open and close the valves • 8-1/2ʺ overall length supplies • 10ʺ overall length supplies leverage
ATSK3621 Hex-to-Square Adaptor leverage while being compact while compact size allows for
• Used with the B2192 Impact enough to be easily carried easy carrying
Pentagon Socket to remove and • Big-mouth adjustable wrench has • Big-mouth adjustable wrench has
tighten special bolts used by large, 1-1/2ʺ capacity large, 1-3/4ʺ capacity
electrical utilities on • 3/4ʺ valve wheel wrench opening • 3/4ʺ valve wheel wrench opening
pad-mounted and sub-surface • Precision hardened and • Precision hardened and anti-
underground facilities anti-corrosion treate corrosion treated
• 7/16ʺ hex, 1/2ʺ square adaptor • Easy-to-read size measurement • Easy-to-read size measurement TOOLS
• 3ʺ long scale: SAE on one side, metric on scale; SAE on one side, metric on
the other the other

RAILROAD SERVICE TOOLS

5703747UPA IM728NT IM736NT
Lag Screw Sockets, inches
Stock No. A B C D E
1-1/8 x 7/8 5703747UPA 1-7/8 2-1/8 1-3/4 3-1/2 7/8
1 IM728NT 1-3/4 2-1/8 31/32 2-1/8 13/16
1-1/8 IM736NT 1-13/16 2-1/4 1-3/32 2-1/4 3/4
5703747UPA Rectangular Head Lag Socket IM728NT Lag Screw Socket
• For use on special rectangular head lag screws • 1ʺ drive, 1ʺ square
• Rectangular head timber screw spikes are used to secure the rail anchor or rail clip IM736NT Lag Screw Socket
• The screw spikes are used by all railroads to varying degrees, but mainly the North • 1ʺ drive, 1-1/8ʺ square
American freight railroads (BNSF, NS, CSX, UPRR, KCS, CP Rail and CN Rail)
• The opening is 1-1/8 x 7/8ʺ with a 1ʺ square drive and can be used on an impact wrench

• Do not use “cheater bars” on handles 499
• Do not use chrome or industrial finish hand tools with impact drivers
• Read and follow all instructions
• Read safety precautions on pages W1 to W4
