HEAVY-DUTY TRUCK SERVICE TOOLS

Impact Sockets
®
SIMM182 3/4ʺ Drive 6-Point Metric 18 mm Flank Drive Deep
Impact Socket
• Used for removal and installation of the head bolts on VT365
®
International engines found in many delivery vehicles
®
SIMML180 1/2ʺ Drive 6-Point Metric 18 mm Flank Drive Extra-Deep
Impact Socket GENERAL
• Applications include the removal and installation of the fuel tank hold SIMM182
down strap on International 4400 chassis
®
• The fuel tank must be removed to replace the fuel sending unit
• 5ʺ long to reach through the frame to access the fastener without the
need of an extension
S6224 1/2ʺ Drive 6-Point SAE 3/4ʺ 30/30 Air Brake Chamber
Impact Socket SIMML180
• Extra-long design allows for quick and safe removal of long-threaded
brake release stud assemblies
®
• Snap-on sockets using the Flank Drive wrenching system grip the
®
fastener on the flanks/flats, delivering 15–25% more turning power
®
• Snap-on impact sockets are heat treated to optimize impact
service life with a lower hardness than hand sockets and are able to
withstand repeated cycling loads of impact wrenches
• Snap-on uses a proprietary blend of special alloy socket steel that
®
provides long life and great strength
S6314 Extra-Long Impact Socket HAND
• Manufactured from special alloy steel, precision forged and heat S6224 S6314
treated for optimum strength and durability
®
• Flank Drive grips fastener on the flanks/flats, increasing torque by
15-20%, prevents the fastener from rounding and increases the life
of the socket
• 3-1/4ʺ overall length
S6412 Drive Train Bolt Socket S6412
• Removes drive train bolts on Ford vehicles, Hino 268 Box
®
®
®
trucks, International 4200 VT365 box trucks and 2007 Freightliner
®
M2 trucks
S6413 1/2ʺ Drive 12-Point 13 mm Heavy-Duty Driveline Socket
• Designed to service heavy-duty diesel truck drivelines
• Heat treated to a low hardness range compared to chrome sockets, so S6413
that under heavy, continuous use will withstand the impact blows and TOOLS
wear rather than break
• 1/2ʺ drive, 12-point, 13 mm, 4-1/8ʺ long
S6624 3/4ʺ Drive 12-Point 24 mm Main Cap Bolt Socket
• For the removal and installation of the main cap bolts on 2007–later
®
Detroit Diesel DD13 and 15 engines
• Overall length (5-3/4ʺ) and square drive (3/4ʺ) of this socket are
critical due to the torque rating for this application
• Manufactured from special alloy steel, precision forged and heat
treated for optimum strength and durability
• Flank Drive wrenching system grips fastener on the flanks/flats,
®
increasing torque by 15–20%, prevents fastener from rounding and S6624
increases the life of the socket
SIM462TW 3/4ʺ Drive 6-Point 1-7/16ʺ SAE Deep Thin-Wall
Impact Socket
• Designed to remove the lug nuts from Caterpillar Model 793
®
mining trucks
• Thin-wall design accommodates easy removal of the 72 lug nuts
spaced only 6 mm apart on each wheel
• Flank Drive wrenching system grips the fastener on the flanks/flats,
®
delivering 15–20% more turning power
SIM462TW
Special Application Sockets
IPSTML8 1/4ʺ Drive 6-Point 8 mm Metric Deep-Flex Impact Socket
• Removes and installs glow plugs
• Designed with a retention O-ring that holds the glow plug in the
socket while being installed or removed
• Manufactured from special steel with a higher alloy content IPSTML8
• Industrial finish helps protect against corrosion
• Precision machined and heat treated for optimum strength
and durability
491
• Read safety precautions on pages W1 to W4
