HEAVY-DUTY TRUCK SERVICE TOOLS
TOOLS S6160 S6160 1/2ʺ Drive 12-Point Metric 12 mm Extra-Long

Hand Sockets

Head Bolt Socket
®
• Use on 1986–later Nissan engines with 12 mm head bolts
• 8ʺ length reaches past the cam and rocker assembly to service
head bolts
• Thin-profile socket and shank will reach through the access hole
and past the overhead camshaft
• Additional high-torque applications include removal and
®
installation of universal joint flange bolts on Ford /Mercury cars
®
®
such as Mustang , Crown Victoria , Lincoln , Ford Explorer ,
®
®
®
®
®
Ranger and F-150/F-250 trucks ® ®
HAND • For removal of heavy-duty Spicer drive shaft bolts that have
S6260 1/2ʺ Drive 12-Point SAE 1/2ʺ Heavy-Duty Spicer Drive
S6194
Impact Socket
®
®
1/2ʺ fasteners found on Kenworth and Peterbilt trucks, and
many other heavy-duty applications
• 8ʺ long
S6194 1/2ʺ Drive 12-Point Metric 12 mm Head Bolt Socket
®
®
• Used on Toyota and Nissan cars and trucks, and Honda cars
®
with 12 mm head bolts
• 4-1/8ʺ length reaches past the cam and rocker assembly to service
the head bolts
• Thin-profile socket and shank reach through the access hole and
S6190A
past the overhead camshaft
GENERAL
• Additional high-torque applications include removal and
®
®
installation of universal joint flange bolts on Ford Explorer ,
Ranger and F-150/F-250 trucks
®
®
S6190A IPR Sensor Socket for Ford Vehicles
• Used on 1994–later Ford 6.0 L diesel trucks and International
®
®
S6260
CT365, 530E and 466F
®
ber
• Similar to Rotunda part num 303-1112
SHR20 Oil Galley Drain Plug Socket
• For the removal and installation of the oil galley drain plug on
Caterpillar 6 cylinder engines
®
• Galley plugs may leak and need to be removed so a new O-ring
can be installed
• Low-profile design helps get into tight applications
• Special alloy steel provides corrosion resistance
• 1/2ʺ drive, 5/8ʺ Hex socket, 6-point, 1-1/4ʺ long
SHR20
S6100 3/8ʺ Drive 3-Lobe Hand Wheel Socket
• Designed to aid in the removal of rusted and corroded hand
wheels without breaking them
• Manufactured from special steel with a higher alloy content
• Precision forged and heat treated for optimum strength
and durability
• Nickel-chrome plating helps protect against corrosion and makes
it easy to wipe clean
S6100
Impact Sockets
S6197 1/2ʺ Drive 12-Point SAE 1/2ʺ Heavy-Duty Driveline
Impact Socket
®
S6197 • Used on Kenworth and Peterbilt heavy-duty drivelines with
®
1/2ʺ fasteners and many other heavy-duty 1/2ʺ applications
• Socket will clear the weld yoke, when removing the cap screws
holding the wing bushings to the end yoke
• 4-1/8ʺ long
S6199 3/4ʺ Drive U-Bolt Impact Socket
• Used on semi trucks using 5/8ʺ dia. U-bolts for springs and other
suspension components
S6199 • Up to 2ʺ longer than a standard deep socket to easily
accommodate the excess thread length—saves time compared to
cutting off excess thread to use a standard deep socket
• 1-1/8ʺ wrench size, six-point, 3/4ʺ drive, 5ʺ long
