HEAVY-DUTY TRUCK SERVICE TOOLS
TOOLS IM382CD 3/4ʺ Drive 6-Point Metric 30 mm Flank Drive
Impact Sockets
®
Shallow Impact Socket
• Applications include Assault Breacher Vehicle; Utility Truck (Tamen:
D00347K); Abrams M-1 Tank; Bridge Launcher Carrier; M1A2 Heavy Assault
Bridge (hab)/Wolverine, 5420-01-430-4227; Armored Vehicle Launch Bridge
(M60A1 and M48A5); Combat Tank, Ft, 120 mm gun (M1A1)
• 3/4ʺ drive, 30 mm
IM382CD
®
IMFDL242 3/4ʺ Drive 12-Point SAE 3/4ʺ Flank Drive Deep Thin Wall
Impact Socket
• Designed to remove the head bolts on Caterpillar C12, C15, C16 and
®
3406E where the front two and back two head bolts are positioned under
HAND • Additional applications include Detroit Diesel main bearing cap bolts and
the valve covers
®
• Applications on certain Caterpillar head bolts require a thin walled socket
of a certain length
IMFDL242
®
19 mm head bolts on Mercedes-Benz MBE904/MBE906 EGR engines
®
(2007–later)
®
• Snap-on impact sockets are heat treated to optimize impact service life
with a lower hardness than hand sockets and are able to withstand repeated
cycling loads of impact wrenches
• Snap-on uses a proprietary blend of special alloy socket steel that provides
®
long life and great strength
®
• Flank Drive wrenching system delivers up to 20% more turning power
®
without slipping or rounding, while exceeding ANSI performance standards
®
GENERAL
IMSLE242A IPRD20 IMSLE242A 3/4ʺ Drive E24 Inverted TORX Impact Socket
®
• Applications include removal and installation of head bolts on MaxxForce
11 and 13 engines found on D15 International (2010–current)
®
• Manufactured from special alloy steel, precision forged and heat treated for
optimum strength and durability
IPRD20 1/2ʺ Drive 12-Point SAE 5/8ʺ Low Profile Swivel Impact Socket
®
• Snap-on impact sockets are heat treated to optimize impact service life
with a lower hardness than hand sockets and are able to withstand repeated
S6116
cycling loads of impact wrenches
®
• Snap-on uses a proprietary blend of special alloy socket steel that provides
long life and great strength
®
• Flank Drive wrenching system delivers up to 20% more turning power
without slipping or rounding, while exceeding ANSI performance standards
®
• 30° uninterrupted swivel action for greater accessibility in tight quarters,
S6126 allowing for easier and faster removal of stubborn fasteners
®
®
®
• Used on starter bolts on Cummins , Caterpillar , Detroit Diesel and
International engines where housing is in the way when backing out the
®
fastener using a standard-length impact socket
S6116 1/2ʺ Drive 6-Point Metric 16 mm Impact Socket
• Socket is 4ʺ long for easier access to head bolts
• Manufactured from special steel with a high higher alloy content
S6213 • Industrial finish helps protect against corrosion
• Precision machined and heat treated for optimum strength and durability
S6126 1/2ʺ Drive Double Hex 3/4ʺ Driveline Socket
• Socket is 6ʺ long to easily reach driveshaft bolts
• Manufactured from special steel with a higher alloy content
• Industrial finish helps protect against corrosion
• Precision machined and heat treated for optimum strength and durability
S6213 1/2ʺ Drive 12-Point Metric 13 mm U-Joint Strap Bolt Impact Socket
®
®
• Used for removal of 13 mm U-joint strap bolts found on Volvo , Mack and
other heavy-duty applications
• 8ʺ long
S6220 C15 Impact Socket for Caterpillar Engines
®
S6220
®
• Used on Caterpillar C15 engine rocker stud bolts where the length and
broach depth of the socket are critical for the application
• 1/2ʺ drive, 6-point, 11/16ʺ, 3-1/4ʺ long
S6221 Fuel Injector Adaptor Impact Socket
• Used for the removal and installation of the fuel injector adaptor from the
high-pressure rail and for servicing the O-rings on Navistar DT466/570,
®
HT570 (DT9 and 10) engines
• Similar to the Navistar OEM tool part number ZTSE4725
®
• 1/2ʺ drive, 1-1/16ʺ hex
S6221
