TORQUE DRIVERS Preset Torque Screwdrivers
TORQUE QDRIVER3P • Ideal for low-torque assemblies and precision application

• Drivers accept all standard 1/4ʺ hex screwdriver bits
• Cam over torque limiting clutch-free wheels when set torque is achieved
• Accuracy is ±6% from 20–100% of full scale in clockwise direction only for all
drivers in series
• Lightweight construction features aluminum body with steel shank
• Comfortable ergonomic tri-lobe grip and magnetic bit retention
• Textured body provides a nonslip grip
• Not supplied with Certificate of Calibration
• When ordering, user must designate desired torque rating to be set
Range, min
Stock No.
Range, max
32 in-oz (22 N•cm)
6 in-oz (4 N•cm)
4-9/16
QDRIVER1P
5-5/8
10 in-oz (7 N•cm)
QDRIVER2P
15 in-lb (169 N•cm)
5-5/8
QDRIVER3P 1.5 in-lb (16 N•cm) 100 in-oz (70 N•cm) Length, inches
QDRIVER4P 4 in-lb (45 N•cm) 40 in-lb (451 N•cm) 6
ASME B107.300-2010 Type III, Class A, Style 2, Design A
®
Adjustable Torque Screwdrivers
• Ideal for low-torque assemblies, precision applications and dash/under dash work on
most domestic and imported vehicles
• Drivers accept all standard 1/4ʺ hex screwdriver bits
• Cam over torque limiting clutch-free wheels when set torque is achieved
• Accuracy is ±6% from 20–100% of full scale in clockwise direction only for all drivers
in series
QDRIVER3
• Lightweight construction features body with steel shank
• Comfortable ergonomic tri-lobe grip and magnetic bit retention
• Textured body provides a nonslip grip
Stock No. Range Increments Length, inches
QDRIVER2 20–100 in-oz (14–70 N•cm) 1 in-oz 5-7/16
QDRIVER3 3–15 in-lb (3–169 N•cm) 0.2 in-lb 6-1/4
QDRIVER4 5–40 in-lb (56–451 N•cm) 0.5 in-lb 6-11/16
QDRIVER4NM 50–450 N•cm 5.0 N•cm 6-11/16
ASME B107.300-2010 Type III, Class A, Style 1, Design A
®
TPMS Torque Screwdriver
Stock No. Description Range, Dedicated Length Accuracy
QDTPMS35 TPMS Adjustable Torque Screwdriver 4 in-lb, 12 in-lb, 35 in-lb 6-5/8 ±6%
QDTPMS35 TPMS Adjustable Torque Screwdriver
• Highly accurate torque tool intended for maintaining or installing popular styles of tire
pressure monitoring sensors
QDTPMS35 • Manufactured from aircraft-grade aluminum
• Dedicated torque measurements for popular TPMS ratings (4, 12, 35 in-lb)

Torque Limiting Drivers
Stock No. Range, minimum Range, maximum Increments Length, inches
QTS135 5 in-lb 35 in-lb 0.5 in-lb 7
QTSP135 5 in-lb 35 in-lb 0.5 in-lb 7-1/2
QTS135 Adjustable Limiting Driver
• Micrometer-type adjustment
• Clutch allows 25° of free rotation upon reaching the set torque
• Guaranteed accuracy: within ±4% of setting from 20% of capacity to full capacity
QTS135
clockwise and counterclockwise
QTSP135 US Preset Limiting Driver
• Clutch mechanism to help prevent over-torquing by allowing free rotation upon
reaching the set torque
• Ideal selection for assembly line work where the same requirement is constant
• Can be reset at different torque values or readjusted for accuracy whenever necessary
with a torque tester
• Torque limit is pre-set at the factory so when ordering, user must designate desired
torque rating to be set
