TORQOMETER TORQUE WRENCHES

TEC175 TEC175L TORQUE

Combination US/Metric Reading/Standard 2% Accuracy
Square Follow up Head
Drive, Stock No. Models Stock Signal Models Metric Range Metric US Range US Length, Width, Depth*, Storage
inches No. Stock No. Increments Increments inches inches inches Case
1/4 TEC1A TEC1FUA — 16 kg•cm 1 kg•cm 15 in-lb .5 in-lb 9-29/32 2-11/16 1-1/4 PB9
1/4 TEC3A TEC3FUA — 35 kg•cm 1 kg•cm 30 in-lb 1 in-lb 9-29/32 2-11/16 1-1/4 PB9
1/4 TEC6A TEC6FUA — 90 kg•cm 2.5 kg•cm 75 in-lb 1 in-lb 9-29/32 2-11/16 1-1/4 PB9
3/8 TEC12A TEC12FUA TEC12LA 175 kg•cm 5 kg•cm 150 in-lb 5 in-lb 9-29/32 2-11/16 1-1/4 PB9
3/8 TEC25FA TEC25FFUA TEC25FLA 350 kg•cm 10 kg•cm 25 ft-lb 1 ft-lb 9-29/32 2-11/16 1-1/4 PB9
3/8 TEC50A TEC50FUA TEC50LA 700 kg•cm 20 kg•cm 600 in-lb 20 in-lb 12-1/2 2-11/16 1-1/4 PB9
1/2 TEC51 TEC51FU TEC51L 700 kg•cm 20 kg•cm 600 in-lb 20 in-lb 15 2-11/16 1-5/16 —
1/2 TEC100 TEC100FU TEC100L 14 kg•m .5 kg•m 100 ft-lb 2 ft-lb 16 2-3/4 1-3/8 PBR5
1/2 TEC175 TEC175FU TEC175L 25 kg•m 1 kg•m 175 ft-lb 5 ft-lb 18-3/4 2-3/4 1-3/8 PBR5
1/2 TEC250 TEC250FU TEC250L 35 kg•m 1 kg•m 250 ft-lb 10 ft-lb 23-3/4 2-3/4 1-3/8 PB8A
3/4 TEC352A TEC352FUA TEC352LA 50 kg•m 1 kg•m 350 ft-lb 10 ft-lb 29-7/8 3-1/4 1-25/32 PB39
3/4 TEC602A TEC602FUA TEC602LA 80 kg•m 2 kg•m 600 ft-lb 20 ft-lb 40-7/8 3-1/4 1-25/32 PB39
1 TEC803** TEC803FU** TEC803L** 110 kg•m 2 kg•m 800 ft-lb 25 ft-lb 66-13/16 3-9/16 2-1/32 —
1 — — TEC1003L** 136 kg•m 2 kg•m 1,000 ft-lb 20 ft-lb 66-13/16 3-9/16 2-1/32 —
1 — TEC1503FU† TEC1503L† 200 kg•m 5 kg•m 1,500 ft-lb 25 ft-lb 80 4-13/32 2-1/8 —
1 — TEC2003FU† TEC2003L† 280 kg•m 5 kg•m 2,000 ft-lb 50 ft-lb 80 4-13/32 2-1/8 —
1-1/2 TEC2005† TEC2005FU† TEC2005L† 280 kg•m 5 kg•m 2,000 ft-lb 50 ft-lb 80 4-13/32 2-3/8 —
1-1/2 TEC3005 TEC3005FU TEC3005L 400 kg•m 5 kg•m 3,000 ft-lb 50 ft-lb 140 5-1/2 2-13/16 —
*Does not include square drive dimension. **Includes separately packed 92TQPA 4’ tubular extension handle.
†Includes separately packed 93TQPA 5’ tubular extension handle.
Wrenches in chart do not include certificate of calibration. Wrenches with a certificate of calibration are available.
Basic model= 1 needle Follow-Up = 2 needles Signal = signal light

TEX602TLA 85TQP TEX2003TFU

US Reading/Standard 2% Accuracy Optional “T” Bars/
Extension Handles
Input Drive Output Ext.
Female Drive Male Follow up Models Light Signal US Range, US Length, Width, Head Increments, “T” Length, Ext. Handle
Square, Square, Stock No. Models ft-lb Increments, inches inches Depth, ft. lb. Bars inches Handle Length,
inches inches Stock No. ft-lb inches inches
3/4 3/4 TEX602TFUA * TEX602TLA * 600 10 9 3-1/4 3-3/4 — 81TQP 66 — —
3/4 1 TEX1003TFUA TEX1003TLA 1,000 10 9-7/8 3-5/8 4-1/8 — 81TQP 66 — —
1 1 TEX1503TFU TEX1503TL 1,500 25 10-7/8 4-3/8 4-7/16 82TQP 18 85TQP 31
1 1 TEX2003TFU TEX2003TL 2,000 — 10-7/8 4-3/8 4-7/16 25 82TQP — 85TQP 31
1 1-1/2 TEX2005TFU TEX2005TL 2,000 25 10-7/8 4-3/8 4-7/16 — 82TQP 18 85TQP 31
1-1/2 1-1/2 TEX3005TFU — 3,000 50 12 5-1/8 6-1/2 — 83TQP 18 87TQP 66
1-1/2 1-1/2 TEX4005TFU TEX4005TL 4,000 50 12 5-1/8 6-1/2 — 84TQP 20 89TQP 72
Wrenches in chart do not include certificate of calibration. Wrenches with a certificate of calibration are available by adding “C” to the end of the stock number.
*T-Bar not included
Basic model= 1 needle Follow-Up = 2 needles Signal = signal light

335
• Do not exceed rated torque
• Do not use to break fasteners loose
• Periodic recalibration is necessary to maintain accuracy
• Read safety precautions on pages W1 to W4
