ADJUSTABLE CLICK-TYPE

BRUTUS3R300 QD2RN100A
Torque Wrenches TORQUE
Square Head Head Ratchet
Drive, Stock No. Head Style Gear Swing Range, Range, Increments Length, Width, Depth, Storage Service
inches Teeth Arc minimum maximum inches inches inches Case Kit
Fixed
1/2 BRUTUS3R300 Ratchet 36 10° 60 ft-lb 300 ft-lb 2 ft-lb 32-1/2 1-3/4 3/4 PBTQ4 RKRS80A
Fixed
3/8 QD2RN100A 80 4.5º 20 N•m 100 N•m .5 N•m 15-9/16 1-5/32 9/16 PBQD2 RKRF80
Ratchet
BRUTUS3R300 1/2ʺ Drive Adjustable Click-Type Torque Wrench (60–300 ft-lb)
• Expanded range allows extended coverage with the 1/2ʺ drive tool servicing a majority of
vehicles and large pickup trucks
• Gives the user additional range in applying torque and angle on high-torque applications
• Stamped scale (ft-lb) offers better permanency and visibility
• Features heavy-duty components; thicker diameter main tube, cam and internal
components for strength and durability
• Accuracy is ±6% CW and CCW

QD3RM30A

Metric Torque Instruments (kg m, kg cm)
Square Gear Swing Length, Head Head Storage
Drive, Stock No. Head Style Teeth Arc Range, min Range, max Increments inches Width, Depth, Case Repair Kit
inches inches inches
3/8 QD2RM1000A Flex Head 80 4.5º 200 kg•cm 1,000 kg•cm 5 kg•cm 15-9/16 1-5/32 9/16 PBQD2 RKRF80
1/2 QD3RM30A Fixed Ratchet 80 4.5º 6 kg•m 30 kg•m .2 kg•m 19 1-5/8 3/4 PBQD3 RKRS80A
“A” suffix models feature roll-marked tubes and 80 tooth gears

QD1RN6A
QD1RN25A QD2RN25A

Newton Meter Torque Wrenches/±4% Accuracy

Square Gear Swing Range, Range, Length, Head Head Storage Ratchet
Drive, Stock No. Head Style Teeth Arc minimum maximum Increments inches Width, Depth, Case Service Kit
inches inches inches
1/4 QD1RN6A Fixed Ratchet 36 10° 1 N•m 6 N•m .05 N•m 9-7/8 7/8 7/16 PBQD1 RKRT936
1/4 QD1RN25A Fixed Ratchet 36 10° 5 N•m 25 N•m .1 N•m 11-3/4 7/8 7/16 PBQD1 RKRT936
3/8 QD2RN25A Compact Ratchet 36 10° 5 N•m 25 N•m .1 N•m 11-3/4 7/8 7/16 PBQD2 RKRFC936
3/8 QD2RN50A Fixed Ratchet 80 4.5º 10 N•m 50 N•m .5 N•m 15-9/16 1-5/32 9/16 PBQD2 RKRF80
3/8 QD2RN100A Fixed Ratchet 80 4.5º 20 N•m 100 N•m .5 N•m 15-9/16 1-5/32 9/16 PBQD2 RKRF80
1/2 QD3RN200A Fixed Ratchet 80 4.5º 40 N•m 200 N•m 2 N•m 19 1-5/8 3/4 PBQD3 RKRS80A
1/2 QD3RN350A Fixed Ratchet 80 4.5º 70 N•m 350 N•m 2 N•m 24-3/16 1-5/8 3/4 PBQD3 RKRS80A
3/4 QD4RN800A Fixed Ratchet 32 11º 150 N•m 800 N•m 5 N•m 42-3/4 2-1/2 1-1/4 PBQC4 RKRQC4
1 QD5RN1500A Fixed Ratchet 30 12° 300 N•m 1,500 N•m 10 N•m 68.4 3-1/8 1-1/2 S10-117-6 RKRQC5
“A” suffix models feature roll-marked tubes

• Do not exceed rated torque 331
• Do not use to break fasteners loose
• Periodic recalibration is necessary to maintain accuracy
• Read safety precautions on pages W1 to W4
