CONTROLTECH INDUSTRIAL TORQUE WRENCHES
TORQUE CTECH3FR250A • Torque and Angle combo modes • Complies with ISO -6789-2003
Standard Models/2% Accuracy/Ratcheting Head
FEATURES:
®
CTECH2Y100A
provide the most accurate and fastest
and ASME B107.300 (B107.28)
®
Standards for Electronic Torque
way to achieve torque plus angle in a
single motion (patent pending)
Instruments
• CTECH wrenches are manufactured
• Built-in calibration factor for different
with an all-steel body for
head lengths (patent pending)
• Dual side LED indicator lights with
strength • CTECHL wrenches are
manufactured for rugged black
configurable settings
CTECH4R600A
• Large LCD screen with backlight
anodized 6061-T aerospace
• Four indicator modes: LCD, LED,
aluminum from durability and
audible, vibratory
reduced weight SPECIFICATIONS:
• Presets with lockout ability
• Sequence programming and
• Angle Accuracy: ±1% of reading, ±1° @
CTECHL1J240A
job mode • Torque Accuracy: ±2%CW, ±3CCW
Angular Velocity >10°/Sec < 180°/Sec
• USB downloadable data • Angle Range: 0–360°
CTECHL1R240A • Industry-leading two year warranty • Storage Capacity: 1,500 readings
• Includes storage case • Number of Presets: 50
• Operating Temperature: 0–130 °F
(-18–54 °C)
CTECHL1240A • Storage Temperature: 0–130 °F
(-18–54 °C)
Standard Models/2% Accuracy/Interchangeable Head
CTECHAN30A
• Snap-on ControlTech Industrial • In addition to the LED indicator
®
®
Electronic Torque Wrenches are lights, an audible beep and handle
fully programmable for reliable and vibration alert the user when target
consistent torque application torque is achieved
CTECH1MR100 • Torque plus Angle combo modes • The rugged all-steel construction is
allow the user to simultaneously designed to stand-up to even the
complete precise “torque plus turn” toughest work conditions
specifications in a single motion
CTECH2MR100
Square Torque Torque Shank
Gear Gear
Torque
Length,
Stock No. Head Type Drive, Teeth Action Range, Range, Range, N•m Diameter, Weight, lb inches (mm)
(kg)
inches in-lb ft-lb inches
CTECH1FR240A* Sealed Flex Head 1/4 72 5° 12–240 1.0–20.0 1.4–27.2 — 2.0 (.9) 14.1 (358)
CTECH1R240A* Fixed Head 1/4 72 5° 12–240 1.0–20.0 1.4–27.2 — 2.0 (.9) 14.1 (358)
CTECH2FR100A** Sealed Flex Head 3/8 80 4.5° 60–1,200 5.0–100.0 6.8–135.6 — 2.7 (1.2) 17.2 (437)
CTECH3FR250A*** Sealed Flex Head 1/2 80 4.5° 150–3,000 12.5–250 16.9–339 — 4.5 (2.10) 26.7 (678)
CTECH4R600A† Sealed Fixed Head 3/4 32 11° 360-7,200 30–600 40.7–813.5 — 10.5 (4.8) 48.6 (1,234)
CTECH1J240A Interchangeable — — — 12–240 1.0–20.0 1.4–27.2 J (0.425ʺ) 1.8 (0.8) 12.5 (318)
CTECH2Y100A Interchangeable — — — 60–1,200 5–100 6.8–135.6 Y (0.560ʺ) 2.7 (1.2) 17.2 (437)
CTECH3X250A Interchangeable — — — 150–3,000 12.5–250 16.9–339 X (0.735ʺ) 3.6 (1.6) 24.1 (612)
CTECH4Z600A Interchangeable — — — 30–600 360–7,200 40.7–813.5 Z (0.990ʺ) 7.6 (3.5) 44.8 (1,138)
CTECHL1J240A Interchangeable — — — 1.0–20.0 12–240 1.4–27.2 J (0.425ʺ) 1.0 (0.45) 12.5 (316)
0.80 (0.36)
CTECH1JM240 Interchangeable — — — 12–240 1–20 1.36–27.12 J (0.425ʺ) w/battery, 10.15 (258)
excluding case
CTECHL1R240A Sealed Fixed Head 1/4 72 5° 12–240 1.0–20.0 1.4–27.2 — 1.2 (0.54) 14.1 (358)
CTECHL1240A Fixed Head 1/4 — — 1.0–20.0 12–240 1.4–27.2 — 1.1 (0.49) 12.4 (315)
IZO/ISO 2.85 (1.2) 17.8 (452)
CTECHAN135A (Interchangeable) — — — 60–1,195 5.0–99.6 6.8–135.0 9 x 12 mm w/o head, w/ w/o head
batteries
IZO/ISO 2.0 (.9) w/o 13.3 (338)
CTECHAN30A — — — 1.11–22.13 13.3–365.5 1.50–30.00 9 x 12 mm head, w/
(Interchangeable) batteries w/o head
IZO/ISO 3.75 (1.7) 23.9 (607)
CTECHBN340A — — — 12.5–250.8 150–3,009 17.0–340.0 14 x 18 mm w/o head, w/
(Interchangeable) batteries w/o head
IZO/ISO Interchangeable
CTECHANM30 Head — — — 13.3–265.5 1.11–22.13 1.5–30 9 x 12 mm — —
CTECH1MR240 Fixed Head 1/4 72 5º 12–240 1–20 1.36–27.12 — 0.93 (0.42) 11.6 (295)
CTECH2MR240 Fixed Head 3/8 80 4.5º 12–240 1–20 1.36–27.12 — 0.93 (0.42) 11.6 (295)
CTECH2MR1200 Fixed Head 3/8 80 4.5º 60–1,200 5–100 6.8–135.6 — 1.6 (.73) 15.4 (391)
CTECH1MR100 Fixed Head 1/4 72 5º 5–100 0.42–8.33 0.57–11.30 — 0.9 (0.41) 10.9 (267)
10.9
CTECH2MR100 Fixed Head 3/8ʺ 72 5º 5-100 0.42 - 8.33 0.57 - 11.30 — 0.9 (0.41)
(267.05)
CTECHYM1200 Interchangeable — — — 60–1,200 5–100 6.8–135.6 Y (0.560ʺ) 1.4 (.63) 13.75 (349)
*Uses Ratchet Service Kit RKRT72A Includes three AAA Lithium batteries. **Uses Ratchet Service Kit RKRF80. Includes three AA Lithium batteries.
328 ***Uses Ratchet Service Kit RKRS80A. Includes three AA Lithium batteries. †Uses Ratchet Service Kit RKRQC4. Includes three AA Lithium batteries.
CTAL Torque Wrenches include three AAA Lithium batteries.
