T-HANDLE TORQOMETER TORQUE WRENCHES
3/4 TORQUE TEXC602TFUA TEXC4005TL

Combination US/Metric Reading/Standard 2% Accuracy Optional “T” Bars/
Extension Handles
Input Output Ext.
Drive Drive Follow-up Models Light Signal Models US US Metric Length, Width, Head T Bar Ext. Handle
Female Male Stock No. Stock No. Range, Increments, Range, kg•m inches inches Depth, “T” Bar Length, Handle Length,
Square, Square, ft-lb ft-lb kg•m inches inches inches
inches inches TEXC602TFUA TEXC602TLA 600 20 80 2 9 3-1/4 3-3/4 81TQP 66 — —
3/4
3/4 1 TEXC1003TFUA TEXC1003TLA 1,000 20 136 2 9-7/8 3-5/8 4-1/8 81TQP 66 — —
1 1 TEXC1503TFU TEXC1503TL 1,500 25 200 5 10-7/8 4-3/8 4-7/16 85TQP 31 82TQP 18
1 1 TEXC2003TFU TEXC2003TL 2,000 50 280 5 10-7/8 4-3/8 4-7/16 82TQP 18 85TQP 31
1 1-1/2 TEXC2005TFU TEXC2005TL 2,000 50 280 5 10-7/8 4-3/8 4-7/16 82TQP 18 85TQP 31
1-1/2 1-1/2 TEXC3005TFU TEXC3005TL 3,000 100 400 5 12 5-1/8 6-1/2 83TQP 18 87TQP 66
1-1/2 1-1/2 TEXC4005TFU TEXC4005TL 4,000 100 550 10 12 5-1/8 6-1/2 84TQP 20 89TQP 72
​ Wrenches​in​chart​do​not​include​certificate​of​calibration.​Wrenches​with​a​certificate​of​calibration​are​available​by​adding​“C”​to​the​end​of​the​stock​number.
*T-Bar not included
Basic​model=​1​needle​ Follow-Up​=​2​needles​ Signal​=​signal​light

TORQOMETER TORQUE DRIVERS – 1/4" DRIVE
®

US Reading Standard/2% Accuracy TQS012A
Standard Basic Standard Follow-up Length, Stubby Basic Stubby Follow-up Length,
Models Stock No. Models Stock No. inches Models Stock No. Models Stock No. inches Range Increments
TQS004A TQS004FUA 8-5/8 — TQSS004FUA 5-3/4 8 in-oz 1/4 in-oz
TQS008A TQS008FUA 7-3/4 — TQSS008FUA 5-1/4 16 in-oz 1/2 in-oz
TQS012A TQS012FUA 7-3/4 TQSS012A TQSS012FUA 5-1/4 24 in-oz/1.5 in-lb 1/2 in-oz/1/32 in-lb
TQS025A TQS025FUA 7-3/4 TQSS025A TQSS025FUA 5-1/4 48 in-oz/3 in-lb 1 in-oz/1/16 in-lb
TQS050A TQS050FUA 7-3/4 TQSS050A TQSS050FUA 5-1/4 96 in-oz/6 in-lb 2 in-oz/1/8 in-lb
TQS1A TQS1FUA 7-3/4 TQSS1A TQSS1FUA 5-1/4 192 in-oz/12 in-lb 4 in-oz/1/4 in-lb
TQS2A TQS2FUA 7-3/4 TQSS2A TQSS2FUA 5-1/4 384 in-oz/24 in-lb 8 in-oz/1/2 in-lb
TQS2.5A TQS2.5FUA 7-3/4 TQSS2.5A TQSS2.5FUA 5-1/4 480 in-oz/30 in-lb 12 in-oz/1 in-lb
TQS4A * TQS4FUA * 8-11/16 TQSS4A * TQSS4FUA 5-1/4 50 in-lb 1 in-lb
TQS6A * TQS6FUA * 8-11/16 TQSS6A * TQSS6FUA 5-1/4 75 in-lb 1 in-lb
*Includes​1/4”​internal​square​drive​in​handle​
Wrenches​in​chart​do​not​include​certificate​of​calibration.​Wrenches​with​a​certification​of​calibration​are​available​by​adding​“C”​to​the​end​of​the​stock​number.​
All​wrenches​include​PB47​Storage​Case.​
Basic​model​=​1​needle​​ Follow-up​=​2​needles

Combination US/Metric Reading/Standard 2% Accuracy TQSC4FUA

Standard Basic Standard Follow-up Length, Stubby Basic Stubby Follow-up Length,
Models Stock No. Models Stock No. inches Models Stock No. Models Stock No. inches Range Increments
— TQSC1FUA 7-3/4 — TQSSC1FUA 5-1/4 17 kg•cm/15 in-lb .5 kg•cm/.5 in-lb
— TQSC2.5FUA 7-3/4 — TQSSC2.5FUA 5-1/4 35 kg•cm/30 in-lb 1.000 kg•cm/1.0 in-lb
— TQSC4FUA* 8-11/16 — TQSSC4FUA* 5-1/4 56 kg•cm/50 in-lb 2 kg•cm/2 in-lb
— TQSC6FUA* — — TQSSC6FUA* 5-1/4 90 kg•cm/75 in-lb 3 kg•cm/5 in-lb
Wrenches​in​chart​do​not​include​certificate​of​calibration.​Wrenches​with​a​certification​of​calibration​are​available​by​adding​“C”​to​the​end​of​the​stock​number.​
All​wrenches​include​PB47​Storage​Case.​ *Includes​1/4”​internal​square​drive​in​handle​
Basic​model​=​1​needle​​ Follow-Up​=​2​needles
