TORQOMETER TORQUE DRIVERS – 1/4" DRIVE
®

Combination US/Newton Meter Reading/Standard 2% Accuracy**
Standard Basic Standard Follow up Length, Stubby Basic Stubby Follow up Length, Range Increments
Models Stock No. Models Stock No. inches Models Stock No. Models Stock No. inches
— TQSI.34FUA 7-3/4 — TQSSI.34FUA 5-1/4 .34 N•m .01 N•m
TQSI055A — 7-3/4 TQSSI.055A — 5-1/4 .055 N•m .001 N•m TORQUE
— TQSI055FUA 7-3/4 — TQSSI055FUA 5-1/4 .055 N•m .001 N•m
— — — TQSSI.11A TQSSI.11FUA 5-1/4 .110 N•m .005 N•m
— — — — TQSSI.70FUA 5-1/4 .70 N•m .02 N•m
— TQSI135FUA 7-3/4 — TQSSI1.35FUA 5-1/4 1.35 N•m .05 N•m
— TQSR1FUA 7-3/4 — — — 1.6 N•cm/15 in-lb 5 N•cm/.25 in-lb
— TQSR2.5FUA 7-3/4 — — — 3.4 N•m/30 in-lb .1 N•m/1 in-lb
— TQSR4FUA* 8-11/16 — — — 5.5 N•m/50 in-lb .1 N•m/1 in-lb
— TQSR6FUA* 8-11/16 — — — 8.4 N•m/75 in-lb .2 N•m/5 in-lb
*Includes 1/4” internal square drive in handle.
**Precise 1% models are available on special order.
Wrenches in chart do not include certificate of calibration. Wrenches with a certificate of calibration are available by adding “C” to the end of the stock number.
®
All wrenches include PB47 Storage Case. ANSI Spec. B107.300 applies to all these models.
Basic model = 1 needle Follow-up = 2 needles

Torque Angle Gauges
TA358 3/8ʺ Square Drive Torque Angle Gauge
• Determines angle controlled torque tightening
• Allows user to follow manufacturer’s specifications
• Used on automotive, diesel and industrial equipment,
plus head bolts and rod bolts on motorcycles
TA360 1/2ʺ Square Drive Torque Angle Gauge
• Allows user to follow manufacturer’s specifications
• Calibrated in degrees in large, easy-to-read increments
TA358

TORQUE SCREWDRIVER

TechAngle Electronic Torque Screwdriver
®
• Four alert modes (LCD, LED, Audible, Vibratory)
• Advanced features: programmable sleep timer, cycle counter, Approaching Target Over
overload indication, calibration alert, battery level, language Target Achieved Torque
selection and torque record memory including 10 presets and
storage for up to 50 records
• Three modes of operation: Torque, Angle, Torque Then Angle
• Displays in seven units of measure: in-lb, in-oz, ft-lb, Nm, Kg-cm,
cNm and angle
• Guaranteed accuracy +/- 2% CW and 3% CCW at 20–100% of full ATECHMS80F

scale (+/- 4% CW and 6% CCW at 5–19% of full scale)
Stock No. Description Range Increments Length, inches
ATECHMS80F 1/4ʺ Hex Electronic Screwdriver (Tool Only) 4-80 in-lb (0.45–9 N•m) .01 in-lb 7-1/2
ATECHMS80FK 1/4ʺ Hex Electronic Screwdriver Kit 4-80 in-lb (0.45–9 N•m) .01 in-lb 7-1/2
ATECHMS100F* 1/4ʺ Hex Electronic Screwdriver (Tool Only) 5–100 in-oz .01 in-lb 7-1/2
ATECHMS80M 1/4ʺ Square Electronic Driver (Tool Only) 4-80 in-lb (0.45–9 N•m) .01 in-lb 7-1/2
ATECHMS80MK 1/4ʺ Square Electronic Driver Kit 4-80 in-lb (0.45–9 N•m) .01 in-lb 7-1/2
ATECHMS100M * ‡ 1/4ʺ Square Electronic Driver (Tool Only) 5–100 in-oz .01 in-lb 7-1/2
MSTECHHDL Electronic Driver L-Handle — — —
*scales are +/-3% CW and CCW (+/- 5% CW and +/-6% CCW) at 5–19% of full scale.
ASME B107.300-2010

• Do not exceed rated torque
• Do not use to break fasteners loose 337
• Periodic recalibration is necessary to maintain accuracy
• ‡ These products can expose you to chemicals which are known to the state of California to cause cancer
and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
