INTERCHANGEABLE HEADS Maximum Maximum
TORQUE QYOM32A 1-1/16 Stock No. J (0.425ʺ) Torque, ft-lb 2-11/16 Stock No. J (0.425ʺ) Torque, ft-lb
Thin Open End Heads, inches

Shank
Shank
Working
Working
(dia.)
(dia.)
60
9/16
2
60
QJO18ARTH
QJO64ARTH
2-1/16
QJO22ARTH60 J (0.425ʺ)
11/16
60
60
J (0.425ʺ)
QJO66ARTH
J (0.425ʺ)
J (0.425ʺ)
60
60
2-1/8
1
QJO32ARTH
QJO68ARTH
60
60
J (0.425ʺ)
J (0.425ʺ)
QJO34ARTH
QJO86ARTH
1-1/8
60
J (0.425ʺ)
1-3/8
J (0.425ʺ)
60
QJO36ARTH
QYO44ARTH
1-3/16
Y (0.560ʺ)
1-1/2
J (0.425ʺ)
60
160
QJO38ARTH
QYO48ARTH
1-1/4
60
J (0.425ʺ)
160
1-3/8
1-5/8
Y (0.560ʺ)
QYO52ARTH
QJO44ARTH
160
1-1/2
60
J (0.425ʺ)
1-3/4
Y (0.560ʺ)
QYO56ARTH
QJO48ARTH
Y (0.560ʺ)
1-7/8
60
J (0.425ʺ)
160
QYO60ARTH
QJO50ARTH
Center of fastener to 1-9/16 QJO40ARTH J (0.425ʺ) 60 1-9/16 QYO50ARTH Y (0.560ʺ) 160
1-5/8
J (0.425ʺ)
160
2
Y (0.560ʺ)
60
QYO64ARTH
QJO52ARTH
retaining pin: 1-11/16 QJO54ARTH J (0.425ʺ) 60 2-1/8 QYO68ARTH Y (0.560ʺ) 160
• QJO Series: 2.50ʺ QJO56ARTH QYO72ARTH
• QYO Series: 3.00ʺ 1-3/4 J (0.425ʺ) 60 2-1/4 Y (0.560ʺ) 160
1-7/8 QJO60ARTH J (0.425ʺ) 60
Thin Open End Heads, mm
Maximum Maximum
Shank Shank
Stock No. Working Stock No. Working
(dia.) (dia.)
Torque, ft-lb Torque, ft-lb
17 QJOM17ARTH J (0.425ʺ) 60 46 QJOM46ARTH — —
18 QJOM18ARTH — —
Open End Heads, mm
O.D., Head Depth,
J (0.425ʺ) Y (0.560ʺ) X (0.735ʺ) Z (0.990ʺ)
mm mm
6 QJOM6A (5) — — — 13 4
7 QJOM7A (6) — — — 15 4
8 QJOM8A (10) — — — 17 4
9 QJOM9A (14) — — — 19 5
Center of fastener to 10 QJOM10A (22) — — — 21 5
retaining pin: 11 QJOM11A (33) — — — 23 6
• QJOM Series: 2.50ʺ 12 QJOM12A (36) — — — 25 6
• QYOM Series: 3.00ʺ 13 QJOM13A (41) — — — 27 6
• QXOM Series: 4.50ʺ
• QZOM Series: 5.75ʺ 14 QJOM14A (55) QYOM14A (55) — — 29 7
15 QJOM15A (60) QYOM15A (74) — — 31 7
16 QJOM16A (60) QYOM16A (88) — — 33 7
17 QJOM17A (60) QYOM17A (103) QXOM17A (103) — 35 8
18 QJOM18A (60) QYOM18A (115) QXOM18A (115) — 37 8
19 QJOM19A (60) QYOM19A (138) QXOM19A (138) — 39 9
20 QJOM20A (60) QYOM20A (160) QXOM20A (160) — 41 9
21 QJOM21A (60) QYOM21A (160) QXOM21A (180) — 43 9
22 QJOM22A (60) QYOM22A (160) QXOM22A (206) — 46 10
23 QJOM23A (60) QYOM23A (160) QXOM23A (229) — 47 10
24 QJOM24A (60) QYOM24A (160) QXOM24A (240) QZOM24ADP (250) 49 11
25 QJOM25A (60) QYOM25A (160) QXOM25A (240) QZOM25ADP (275) 52 11
26 QJOM26A (60) QYOM26A (160) QXOM26A (240) QZOM26ADP (298) 53 11
27 QJOM27A (60) QYOM27A (160) QXOM27A (240) QZOM27ADP (319) 55 12
29 — QYOM29A (160) QXOM29A (240) QZOM29ADP (379) 58 12
30 QJOM30 (60) QYOM30A (160) QXOM30A (240) QZOM30ADP (413) 61 13
32 QJOM32 (60) QYOM32A (160) QXOM32A (240) QZOM32ADP (480) 65 14
34 — QYOM34A (160) QXOM34A (240) QZOM34ADP (480) 68 14
36 QJOM36A (60) QYOM36A (160) QXOM36A (240) QZOM36ADP (480) 74 15
41 — QYOM41 (160) QXOM41A (240) QZOM41ADP (480) 83 18
46 — — QXOM46A (240) QZOM46ADP (480) 93 19
49 — QXOM49A (240) — — 86 18
50 — QYOM50A (160) — QZOM50ADP (480) 102 20
55 — — QXOM55A (240) QZOM55ADP (480) 113 23
60 — QYOM60A (160) — QZOM60ADP (480) 125 27
QXOM60A (240)
65 — — — QZOM65ADP (480) 130 26
70 — — — QZOM70ADP (480) 169 31
342 *Use with QC1P100 and QC1I200 torque bodies only; Value in parentheses is the Maximum
Recommended Working Torque, ft-lb.
other heads may be used with all listed torque bodies
