TORQUE TESTERS

Digital Torque Testers (DTT Series)
• Can be mounted on a wall or in a bench-top vise
• Features an easy-to-use touchscreen to capture peak torque values
during a test in real time
• Download stored torque data to a PC
®
• Testing options: quick check or ASME -style test TORQUE
• Refresh rate of 1,000 data points per second
• Record and track torque wrench test results by serial number, plus
add traceability by using wrench serial numbers and technician I.D.
• Choose wrench type
• ±0.5% of indicated test value from 10–100% or rated capacity
• Memory Capacity: 500 records (complete check mode only)
• Includes AC/DC power supply, (6) AA alkaline batteries, USB cable
and carrying case
• Highly accurate scale (±0.5% ±1 count 10–100% CW and CCW of
indicated test value @ 25 °C)
• Ability to customize between units of measure (N•m, kg-cm, ft-lb, inlb,
in-oz), operation modes (Track, Peak, First Peak) and wrench type
• Operating temperature (10–32 °C/ 50–90 °F) QC3DTT250
• Refresh rate of 1,000 data Points Per Second
• CSA/UL Requirements: Power supply listed under UL (C and US); Stock No. Description
100–240V/ 50–60 Hz, 6 A input and 9 V/1.66 A output DTS8269 AC Adaptor
• Includes a Certificate of Calibration DTS95095 Power Cord, UK
DTS95096 Power Cord, Australia
DTS95097 Power Cord, EU
2344-0050-03 Table Mounting Bracket
For DTT Testers
NOTE: Must order the adaptor and appropriate power cord.

QC2DTT250 QC3DTT250
Square Drive, inches 3/8 1/2
Range English 25–250 in-lb 25–250
Range, N•m 2.9–28.2 33.9–338.9
±0.5% of Indicated Test Value from 10–100% ±0.5% of Indicated Test Value from 10–100%
Accuracy
or Rated Capacity or Rated Capacity
Operating Modes TRACK, PEAK, FIRST PEAK TRACK, PEAK, FIRST PEAK
Operating Temperature 32–122 ºF (0–50 ºC) 32–122 ºF (0–50 ºC)
Humidity 85% Relative Humidity @ 21 °C (70 °F) 85% Relative Humidity @ 21 °C (70 °F)
Power Supply Included 9 V AC/DC Adaptor, (6) AA Batteries Included Included 9 V AC/DC Adaptor, (6) AA Batteries Included
Data/Surge/Recall Memory Capacity—500 Records (complete check mode only) Memory Capacity—500 Records (complete check mode only)

TBTT100A

Horizontal Torque Testers and Transducers
• Includes (3) transducers
• Full digital display
• Covers ft-lb, in-lb, in-oz, N•m, kg-m, kg-cm scales TBT600A
• Peak hold and first peak hold capability
• NIST traceable
®
Stock No. Description Range Resolution
TBT600A Horizontal Torque Tester 5–600 —
TBTT16A Transducer 7.5–200 in-lb .002 ft-lb, 02 in-lb, .002 N•m., .0002 kg-m, .02 kg-cm
TBTT100A Transducer 5–100 .01 ft-lb, 1 in-lb, 2 in-oz, .01 N•m, .001 kg-m, 1 kg-cm
TBTT600A Transducer 30–600 ft-lb .05 ft-lb, 5 in-lb, 10 in-oz, 1 N•m, .01 kg-m., 1 kg-cm

• Do not exceed rated torque 347
• Do not use torque wrenches to break fasteners loose
• Torque multipliers produce very high reaction force, use caution
• Read safety precautions on pages W1 to W4
