ELECTRONIC TORQUE TESTER AND CALIBRATOR
TORQUE TTC2600 • Reaction arms, cables, mounting plates and fixtures are available for testing

Force Testing Equipment

tensiometers, plus compression and tension gauges. The TTC600 and TTC800 loaders
and TTC Series transducers can be configured to deliver compression and tension loads
• The TTC610/TTC810 indicator also provides measurement, display, storage and
statistical analysis for force inputs
Description
Stock No.
Tensiometer Testing Kit
TTC2600
Tension Gauge Testing Kit
TTC2610
Compression Gauge Testing Kit
TTC2620
Force Arm Kit
TTC26302
Force testing feature can only be used with single transducers and CANNOT be used with the TTC400 4-in-1 multi transducer.
TTCCALKIT Calibration Kit
• Includes TTC3200 Weight Set (#1), TTC500 2-1/2ʺ
TTC2610 Calibration Wheel, TTC1510 5ʺ Calibration Wheel, TTC1520
10ʺ Butterfly Calibration Wheel, 2000-226-3 Adaptor
(1/2ʺ x 3/8ʺ), TTC1540 40ʺ Calibration Arm, 390-2-2 4 oz
Calibration Weight Tray, TTC301 8 oz Calibration Weight
Tray, TTC3040 7.5 lb Calibration Weight Tray, TTC3020 15 lb
Calibration Weight Tray, TTC3030 50 lb Calibration Weight
Tray and TTC25002 Calibration Stand Kit
• Kit can be used on all TTC Systems
Accessories
TTC900121 Smart Cable Replacement

TTC2620 TTC26302

Calibration Wheels/Arms
Use to calibrate any TTC Series transducer. Arms are certified to manufacturer’s standards.

Stock No. Description
TTC500 2-1/2ʺ Calibration Wheel (max 50 in-oz)
TTC1510 5ʺ Calibration Wheel (max 150 in-lb)
TTC1520 10ʺ Butterfly Wheel (max 250 ft-lb)
TTC1530 1/2ʺ and 3/8ʺ Drive 20ʺ Calibration Arm
TTC1540 1-1/4ʺ Drive 40ʺ Calibration Arm
TTC75002 Torque Screwdriver Testing Kit (for 2800 and 2000 Series Systems)

Weight Sets Weight Hangers/Trays
Used to calibrate any TTC Series transducer. All weights Used to calibrate any TTC series transducer. Weight trays
are NIST (NBS) traceable. are certified as to weight.
®
Stock No. Description Stock No. Description
TTC3200 No. 1 Weight Set (for all transducers) 390-2-2 Weight Hanger (4 oz)
TTC3210 No. 2 Weight Set (200 in-oz–600 ft-lb) TTC301 Weight Hanger (1/2 lb)
TTC3220 No. 3 Weight Set (600–2,000 ft-lb) TTC3040 Weight Tray (7.5 lb)
TTC3020 Weight Tray (15 lb)
TTC3030 Weight Tray (50 lb)

Joint Rate Simulator Adaptors
• Use with torque tester when testing nonimpacting power tools
• Square drive adaptor is placed on top of square drive of the torque tester and
tightened with a set screw
• Adaptor bit is inserted into the power tool and mated to the top of the joint adaptor
QC2JRS400 • By stacking the Belleville washers in set patterns, the joint rate adaptor can simulate
soft, medium or hard joints
Stock No. Square Drive, inches Capacity, in-lb Adaptor Bit Load Screw
QC1JRS50 1/4 50 1/4ʺ Hex x 3/16ʺ Hex 1/4ʺ x 28 x 1
QC2JRS400 3/8 400 3/8ʺ Square Internal x 3/8ʺ Hex 7/16ʺ x 20 x 1.5
QC2JRS1000 3/8 1,000 3/8ʺ Square Internal x 1/2ʺ Hex 5/8ʺ x 18 x 1.5
