ELECTRONIC TORQUE TESTER AND CALIBRATOR
TORQUE TTC2000 Master Torque Calibration System (Manual) TTC2800SYS Motorized Torque Tester/Calibrator

TTC2800SYS
TTC2000SYS

Complete Master Torque Calibration System (Motorized)
The system tests and calibrates most click-type, digital,
includes: TTC2800 Monitor, Loader and Tool Cabinet w/
dial torque wrenches as well as torque screwdrivers.
Twelve transducers are available in ranges from 5 in-oz
Casters, TTC400 4-in-1 Transducer, TTC5000-1 Bracket,
to 2,000 ft-lb. Also available is the 4-in-1 Transducer,
lb Transducers, TTC5500-1 Extension Arm, 2000-SW
with a range of 4 in-lb to 250 ft-lb. All transducers feature
WedgeLink Software, 2000-50-3 Download Cable
a built-in memory chip that identifies the transducer
Features
and maintains the calibration. Set up and calibration
programming is entered via soft touch keys. The TTC2000 TTC12 3/4ʺ 600 ft-lb Transducer, TTC14 1ʺ 2,000 ft-
• Accuracy: ±0.25% of indicated value, CW and CCW, from
can store and recall up to 3,000 torque readings. 10–100% of full scale
Torque readings stored in memory can be downloaded • Units of Torque: ft-lb, in-lb, in-oz, N•m, dN•m, cN•m,
to a computer with optional download cable and Kgm, Kg-cm
software. Optional kits are available to calibrate cable • Units of Force: lbf, ozf, n, dN, kp, gf
tensionmeters, tension and compression gauges and non- • Four Modes: TRACK, PEAK HOLD, FIRST PEAK, POWER
impact power tools. TOOL
TTC2800/TTC2822 Master Torque Calibration System • Includes built-in low-profile serial printer
(Motorized) • Transducers available from 5 in-oz to 2,000 ft-lb
The TTC2800 has the same features as the TTC2000 series • Loader hand crank maximum input torque is 8 ft-lbs,
except for the following enhanced features: maximum output is 2,000 ft-lb
• Electric motor powered crank for easy calibration • All transducers are individually serialized with
• Is offered in 110 V version (TTC2800/Complete certificates of calibration traceable to N.I.S.T.
TTC2800SYS or 220 V version (TTC2822/Complete • Programmable automatic or manual options for CLEAR,
system TTC2822SYS) STORE or SEND
TTC2000SYS Electronic Manual Torque Tester/Calibrator • RS232 serial port for downloading data to PC
(Manual) includes: TTC610 Digital Monitor, TTC600 • Operating Temperature: 10–32 ºC (50–90 ºF)
2000 ft-lb Mechanical Loader, SM0773PU Tool Cabinet • Automatic lockup in the event of transducer overload
w/ Casters, TTC400 4-in-1 Transducer, TTC5000-1 • Data storage/recall (with date/time stamp) up to 3,000
Bracket, TTC12 3/4ʺ 600 ft-lb Transducer, TTC14 1ʺ 2000 readings
ft-lb Transducer, TTC5500-1 Extension Arm, 2000-SW • Dual Voltage: 110 V or 220 V• Real Time Clock
WedgeLink Software, 2000-50-3 Download Cable. • Smart “Plug and Play” transducers
• NIST traceable
®
TTC2000SYS TTC2800SYS
Description Electronic Manual Torque Tester/Calibrator Motorized Torque Tester/Calibrator
Capacity 8 digits ±32,000 counts (16 bit A/D) 8 digits ±32,000 counts (16 bit A/D)
Accuracy* ±0.25% of reading at 25 °C (with TTC Transducer calibration) ±0.25% of reading at 25 °C (with TTC Transducer calibration)
Temperature Drift +0.03 (+0.017) +0.03 (+0.017)
2-line x 16 character 5 x 8 dot-matrix LCD used for 2-line x 16 character 5 x 8 dot-matrix LCD used for
Maximum Range MAX. Transducer range, Units, Calibration, Date/Time, MAX. Transducer range, Units, Calibration, Date/Time,
Display Statistics, Torque/Force or Torque Limits Set, Statistics, Torque/Force or Torque Limits Set,
Data Store/Recall, Printer Set Up Data Store/Recall, Printer Set Up
Modes Track, Peak Hold, First Peak, Power Tool Track, Peak Hold, First Peak, Power Tool
Operating
Temperature 10–32 (50–90) 10–32 (50–90)
Storage
Temperature -20–50 (-2–122) -20–50 (-2–122)
Humidity Up to 90% Non-Condensing Up to 90% Non-Condensing
Power Supply UL Approved, 120 VAC/220 VAC, 50/60 Hz 120 VAC ±10%, 50/60 Hz @3.14 A (including motor current).
(Includes stepdown transformer for 240 VAC operation.)
Data Storage/
Recall 3,000 Measurements 3,000 Measurements
Statistical Max, Min, Range, Mean, SigmaN, Sigma, Cp, Cpk, % Error, Max, Min, Range, Mean, SigmaN, Sigma, Cp, Cpk, % Error,
Analysis -NoGo, +NoGo -NoGo, +NoGo
Histogram Lower Set Limit, Upper Set Limit, 10 Divisions Lower Set Limit, Upper Set Limit, 10 Divisions
Printer/Computer
Serial Output Port RS232 (True), 300-19.2K Baud RS232 (True), 300-19.2K Baud
Computer Serial
Com Port RS232 (True), 300–19.2K Baud (Optional) RS232 (True), 300–19.2K Baud (Optional)
+(CW/-(CW) 1.8 V at Transducer Full Range Linearity, ±1% of +(CW/-(CW) 1.8 V at Transducer Full Range Linearity, ±1% of
Analog Output reading reading
Loader Control Two, Normally Open, Form A, Rated 12 DVC @ 1/2 A close Two, Normally Open, Form A, Rated 12 DVC @ 1/2 A close
Relays contact at 110% CW or CCW or torque/force transducer range contact at 110% CW or CCW or torque/force transducer range
Loader Hand Input torque 8 ft-lb Maximum, Output Torque 2,000 ft-lb Input torque 8 ft-lb Maximum, Output Torque 2,000 ft-lb
Crank Maximum Maximum
Motorized Loader
Modes — Manual; Auto Dial; Auto Click
Motorized Loader 120 V AC ±10% Hz @ 3.14 A (including motor current); (optional
Power Supply — step-down transformer for 240 V AC operation)
Total Uncertainty: Add 7.5–100% of Range and 8–100% of Range
350 Training programs are available by location (P/N STRN01 to STRN07)
