Pneumatic Tools

Drilling and grinding machines

9035 Needle scaler 9035 V Vibration chisel set
C • Strike rate adjustable in 9 levels up to 2600 strikes/min
• Chisel collet: h 10 mm
1 K l/min. db (A) LpA 5 4 • Shaft collet length: 73 mm
?
N
9035 M-5 235.6 48.1 87.9 480 232284 • Plastic case 1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
Spare needles • Coupler plug: Nominal size 7.2 (included)
For needle scaler 9035 M-5 • Working pressure (bar): 6.3
13 needles, x 1.3 mm • Cold insulated handle
9035 M-050 – – – – 233205
9035 H Chisel hammer set
• Strike rate adjustable in 9 levels up to 2600 strikes/min
• Chisel collet: h 10 mm
• Shaft collet length: 73 mm
• Plastic case
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6.3
• Cold insulated handle

9035 V-05
9035 V-01
9035 V-06
9035 V-02
9035 V-08
9035 V-03
9035 V-09
9035 V-04 9035 V-10

9035 H-01
9035 H-02
9035 H-03
9035 H-04
9035 H-05
1 5 è 4

• Vibration chisel set
• Air requirement: 57 – 594 l/min
• Sound pressure level: 92 – 105 dB(A) Lp A
9035 V/5 2500 5 213368
• Combination basic unit with vibration and hammer function
• Plastic case
1 5 è 4 • Air requirement: 57 – 594 l/min
• Sound pressure level: 92 – 105 dB(A) Lp A
9035 VH 2500 – 214020
• Chisel hammer set • Keyless drill chuck
• Air requirement: 57 – 594 l/min • For 9035 VH ∙ 9035 H/6 ∙ 9035 V/5
• Sound pressure level: 92 – 105 dB(A) Lp A 9035 VH-01 – – 214242
9035 H/6 2500 6 214655 • Spare chisel set for 9035 V/5
• Combination basic unit with vibration and hammer function • Contents: 9035 V-01 ∙ 02 ∙ 03 ∙ 04
• Plastic case 9035 V/4 – 4 214013
• Air requirement: 57 – 594 l/min
• Sound pressure level: 92 – 105 dB(A) Lp A • Semi-circular vibration chisel
9035 VH 2500 – 214020 9035 V-01 – – 214181
• Keyless drill chuck • Circular vibration chisel
• For 9035 VH ∙ 9035 H/6 ∙ 9035 V/5 9035 V-02 – – 214174
3
9035 VH-01 – – 214242 • Vibration chisel i 10 = ⁄8″ / g Ä 19 mm
• Spare chisel set for 9035 H/6 9035 V-03 – – 214167
1
• Contents: 9035 H-01 ∙ 02 ∙ 03 ∙ 04 • Vibration chisel i 12.5 = ⁄2″ / g Ä 19 mm
9035 H/5 – 5 214006 9035 V-04 – – 214150
• Flat chisel • Vibration chisel, flat
9035 H-01 – – 214136 9035 V-05 – – 227266
• Sheet cutting chisel • Vibration drift pin 6 mm
9035 H-02 – – 213924 9035 V-06 – – 227259
• Pointed chisel • Vibration drift pin 8 mm
9035 H-03 – – 214198 9035 V-08 – – 227297
• Rivet cutting chisel • Curved vibration chisel
9035 H-04 – – 214143 9035 V-09 – – 227280
• Curve cutting chisel • Vibration drift pin 10 mm
9035 H-05 – – 214525 9035 V-010 – – 227273

Components and spare parts from page 482 to 490 Valid until December 31, 2021 333
