Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9033 Mini disc sander ∙ angled 9033 Mini disc sander ∙ angled

• Heavy-duty multi-bearing gearbox with a 2.5-times longer C
service life compared to conventional gearboxes
• Optimised for spot repairs
1 ? ^ N 5 è 4
• Application: For processing surfaces even in hard to reach work areas, e.g. for l/min. rpm db (A) LpA
removing rust, stripping paint, removing adhesive and sealing residues, as well as • 5 pieces Abrasive material, red, x 50 mm, 150 grain size
for cleaning/processing surfaces, weld seams, etc. using various abrasive media • Base component: nylon, Abrasive: resin
• Roloc quick-change system: • Roloc connection
®
®
Combine with many abrasive media 9033-11-0150/5 – – – – 5 228256
Fast, tool-free, easy change of abrasives
• Grinding disc diameter: 50 mm Strip wheel set, 4-piece
1
• Grinding disc thread: ⁄4 inch– 20 UNF Ideal for work on tough surfaces of materials such as stainless
• Exhaust air is guided through the handle steel, ferrous metal, non-ferrous metal, aluminium or for
workpieces such as sheet metals, pipes, welding seams
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) • Hard variant
1
• Coupler plug: Nominal size 7.2 (included) • Suitable for rust removal, paint stripping, cleaning welding seams,
• Hose diameter (recommended): 10 mm removing severe surface contamination and coatings
• Working pressure (bar): 6.3 • Use on larger surfaces
• Sound power level: 95.2 db(A) Lp W • High edge strength
• Vibration acceleration: 1.80 m/s 2 • High durability
• Power in watts: 224 watts • Set consisting of 4 discs
• Cold insulated handle • Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Coarse fibre fleece construction
®
• Roloc quick-change system
• Diameter: 50.8 mm
• Recommended rpm: 8000–10000
• Max. rpm: 18000
9033-11-020/4 – – – – – 222834
• 5 pieces Abrasive material, blue, x 50 mm, 300 grain size
• Base component: nylon, Abrasive: resin
• Roloc connection
®
9033-11-0300/5 – – – – 5 228263
Strip wheel set, 4-piece
Ideal for work on tough surfaces
• Soft variant
• Flexible coarse cleaning disc for universal cleaning
applications for use on larger surfaces
• Set consisting of 4 discs
• Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Open fleece structure
®
• Roloc quick-change system
• Diameter: 50.8 mm
• Recommended rpm: 8000–10000
• Max. rpm: 18000
9033-11-030/4 – – – – – 222728
9033-11-020/4 9033-11-030/4 9033-11-036/2
Replacement bristle grinder set, purple, 2 pieces
Ideal for cleaning and gentle deburring
• Enables consistent results and cleaning effect throughout the
entire service life as no pressure is applied when working
®
• Roloc quick-change system allows the plastic brush to be
changed quickly and easily without any extra tool
• Disc can be loosened and tightened at the base plate by simple twisting
• Solid plastic brush offset with ceramic grit
9033-11-050/2 9033-11-080/5 9033-11-0120/2 • Adapts to contours and shape of the workpiece
• Bristle length: approx. 16 mm
• Max. rpm: 25000
• Diameter: 50 mm
• Grain size: 36
9033-11-036/2 – – – – – 222872
9033-11-S 060 • 5 pieces Abrasive material, brown, x 50 mm, 80 grain size
9033-11-S 080
9033-11-0150/5 9033-11-0300/5 9033-11-S 120 • Base component: nylon, Abrasive: resin
®
• Roloc connection
9033-11-080/5 – – – – 5 228270
Replacement bristle grinder set, green, 2 pieces
Ideal for cleaning and gentle deburring
• Enables consistent results and cleaning effect throughout the
entire service life as no pressure is applied when working
• Roloc quick-change system allows the plastic brush to be
®
9033 M-11-015 changed quickly and easily without any extra tool
• Disc can be loosened and tightened at the base plate by simple twisting
• Solid plastic brush offset with ceramic grit
1 l/min. rpm db (A) LpA 5 è 4 • Adapts to contours and shape of the workpiece
^
N
?
9033 M-11 84 18000 84.2 440 – 227129 • Bristle length: approx. 16 mm
• Max. rpm: 25000
• 1 piece Replacement grinding disc • Diameter: 50 mm
1
®
• Roloc connection with ⁄4 inch UNF thread (inside thread) • Grain size: 50
9033 M-11-015 – – – – – 228355 9033-11-050/2 – – – – – 222865
B B
330 Valid until December 31, 2021 Components and spare parts from page 482 to 490
