Pneumatic Tools

Drilling and grinding machines

9033 Mini orbital sander set 9033 Multi sander
C C
A/
1 l/min. rpm db (A) LpA 5 4
N
^
?
9033 N-5 79 15000 80 640 205585
• 10 spare grinding pads, grain size 320, 50 mm diameter
9033-5-01/10 – – – 10 160525
• 10 spare grinding pads, grain size 400, 50 mm diameter 9033-6-01 A/5 9033-6-01/5
9033-5-02/10 – – – 7 160730
• 10 spare grinding pads, grain size 600, 50 mm diameter
9033-5-03/10 – – – 18 160747
• 10 spare grinding pads, grain size 320, 75 mm diameter
9033-5-04/10 – – – 21 160754
• 10 spare grinding pads, grain size 400, 75 mm diameter
9033-5-05/10 – – – 14 160761 9033-6-03/5 9033-6-04/5 9033-6-05/5
• 10 spare grinding pads, grain size 600, 75 mm diameter
9033-5-06/10 – – – 20 160778

9033 Multi sander

• Multi sander for use with brush belts, strip wheels and foil erasers 9033-6-06/5 9033-6-02/5 9033-6-010
• Application: Removal of underseal, sealing compound, rust,
corrosion, paint, plastic film, labels as well as for paint stripping
• Continuous speed regulation via speed regulator on back of handle
• 180° adjustable handle
• Spindle size: 9 mm (Hex)
• Delivery without accessories
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) 9033-6-011 9033-6-040 9033-6-041
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3 1 ? ^ N 5 4
• Sound power level: 82 db(A) Lp W l/min. rpm db (A) LpA
• Vibration acceleration: 0.80 m/s 2 9033 N-6 102 4000 79 1200 209743
• Power in watts: 370 watts • 5 foil erasers (lighter design)
• Cold insulated handle • Adapter 9033-6-010 is required
9033-6-01/5 – – – 1290 160167
• 5 foil erasers (darker version)
• For water-based paints
• Adapter 9033-6-010 is required
9033-6-01 A/5 – – – 1280 160228
• 5 brush belts 23 mm wide, coarse, bent tips
• Removing underbody protection and sealing putty, as well
as paint stripping with rough sand-blasting effect
• Adapter 9033-6-010 is required
9033-6-02/5 – – – 280 160174
• 5 brush belts 11 mm wide, coarse, bent tips
• Removing underbody protection and sealing putty, as well
as paint stripping with rough sand-blasting effect
• Adapter 9033-6-011 is required
9033-6-03/5 – – – 140 160181
• 5 strip wheels
• Adapter 9033-6-041 or 9033-6-040 is required
9033-6-04/5 – – – 150 160198
• 5 brush belts 11 mm wide, fine, straight tips
• Removing paint and rust, without sand-blasting effect
• Adapter 9033-6-011 is required
9033-6-05/5 – – – 120 160204
• 5 brush belts 23 mm wide, fine, straight tips
• Removing paint and rust, without sand-blasting effect
• Adapter 9033-6-010 is required
9033-6-06/5 – – – 260 160211
• 1 piece adapter, 23 mm wide
for brush belts 9033-6-02/5 ∙ 9033-6-06/5
and foil erasers 9033-6-01/5 ∙ 9033-6-01 A/5
9033-6-010 – – – – 213672
• 1 piece adapter, 11 mm wide
for brush belts (9033-6-03/5 ∙ 9033-6-05/5)
9033-6-011 – – – – 213665
• 1 piece adapter for double strip wheels 9033-6-04/5
9033-6-040 – – – – 213641
• 1 piece adapter for single strip wheels 9033-6-04/5
B 9033-6-041 – – – – 213658

Components and spare parts from page 482 to 490 Valid until December 31, 2021 325
