Pneumatic Tools

Drilling and grinding machines

9033 Bristle grinder set 9033 Mini polisher
C C
/ • Heavy-duty multi-bearing gearbox with a 2.5-times longer
service life compared to conventional gearboxes
• Optimised for spot repairs
1 ? ^ N 5 è 4 • Application: For working in areas with difficult access and repair work
l/min.
db (A) LpA
rpm
• Extremely light, handy tool
Replacement bristle grinder set, white, 2 pieces • Grinding disc diameter: 50 mm
Ideal for cleaning and gentle deburring • Grinding disc thread: ⁄16 inch UNF
5
• Enables consistent results and cleaning effect throughout the • Exhaust air is guided through the handle
entire service life as no pressure is applied when working 1
®
• Roloc quick-change system allows the plastic brush to be • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
changed quickly and easily without any extra tool • Coupler plug: Nominal size 7.2 (included)
• Disc can be loosened and tightened at the base plate by simple twisting • Hose diameter (recommended): 10 mm
• Solid plastic brush offset with ceramic grit • Working pressure (bar): 6.3
• Adapts to contours and shape of the workpiece • Sound power level: 94.4 db(A) Lp W
• Bristle length: approx. 16 mm • Vibration acceleration: 1.90 m/s 2
• Max. rpm: 25000 • Power in watts: 224 watts
• Diameter: 50 mm • Cold insulated handle
• Grain size: 120
9033-11-0120/2 – – – – – 222858
9033 Mini right-angle grinder
• Heavy-duty multi-bearing gearbox with a 2.5-times longer service life
compared to conventional gearboxes
• Application: Handy and light tool for working in areas with difficult access
• For grinding wheels: 50 – 59 mm
• For grinding wheel thickness: 1 – 4 mm
• Adjustable protection cover
• Spindle thread: ⁄8 inch 24 UNF
3
• Exhaust air is guided through the handle
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 96.8 db(A) Lp W
• Vibration acceleration: 1.90 m/s 2
• Power in watts: 224 watts
• Cold insulated handle
9033-5-01/10 9033-5-02/10 9033-5-03/10

9033-5-08/10 9033 M-9-010 9033 M-9-011

9033 M-9-01
1 l/min. rpm db (A) LpA 5 4
N
?
^
9033 M-9 84 4500 83.6 600 227235
• 10 spare grinding pads, grain size 320, 50 mm diameter
9033-5-01/10 – – – 10 160525
• 10 spare grinding pads, grain size 400, 50 mm diameter
9033-5-02/10 – – – 7 160730
• 10 spare grinding pads, grain size 600, 50 mm diameter
9033-5-03/10 – – – 18 160747
9033 M-07/10
• 10 spare grinding pads, grain size 800, 75 mm diameter
1 l/min. rpm db (A) LpA 5 è 4 9033-5-08/10 – – – – 228317
N
?
^
• Spare polishing disc, 50 mm diameter
9033 M-7 84 18000 85.8 530 – 227242 9033 M-9-01 – – – – 228362
• 10 cut-off wheels 50 x 1 x 10 mm • 5 spare polishing pads, flat, 50 mm diameter
• For steel and stainless steel 9033 M-9-010 – – – – 228324
• Maximum cutting speed 100 m/s • 5 spare polishing pads, curved, 50 mm diameter
9033 M-07/10 – – – – 10 229680 9033 M-9-011 – – – – 228331
Components and spare parts from page 482 to 490 Valid until December 31, 2021 329
