Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9033 Bristle grinder set 9033 Bristle grinder set

• Gentle, effective cleaning of surfaces / C /
• Roloc quick-change system allows the plastic brush to be changed
®
quickly and easily without any extra tool
• Application: For using with various grinding media to remove rust,
paint, adhesive and sealing residues or to clean metal surfaces
and weld seams when using various abrasive media 1 ? ^ N 5 è 4
1
• Grinding disc thread ⁄4 inch – 20 UNC l/min. rpm db (A) LpA
• Dimensions: 112.1 x 152 x 45 mm 9033-11/17 79 15000 75 540 17 222575
• Contents: Plate bristle grinder
1 basic unit including air connection nipple For adaptation of abrasive substances such as strip wheel
®
1 Roloc System bristle grinding disc (50 mm x) and brush wheels with Roloc™ quick-change system
4 violet strip wheels (hard) ®
4 black strip wheels (soft) • Roloc quick-change system for quick, tool-free assembly
2 violet high-performance disc bristle grinders (grain size 36) • Diameter: 50 mm
1
2 green high-performance disc bristle grinders (grain size 50) • Thread: ⁄4″ – 20 UNC
2 white high-performance disc bristle grinders (grain size 120) 9033-11-015 – – – – – 222841
1 assembly tool
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) Strip wheel set, 4-piece
1
Ideal for work on tough surfaces of materials such as stainless
• Coupler plug: Nominal size 7.2 (included) steel, ferrous metal, non-ferrous metal, aluminium or for
• Hose diameter (recommended): 10 mm workpieces such as sheet metals, pipes, welding seams
• Working pressure (bar): 6.3 • Hard variant
• Sound power level: 86 db(A) Lp W • Suitable for rust removal, paint stripping, cleaning welding
• Vibration acceleration: 3.11 m/s 2 seams, removing severe surface contamination and coatings
• Power in watts: 224 watts • Use on larger surfaces
• Cold insulated handle • High edge strength
• High durability
• Set consisting of 4 discs
• Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Coarse fibre fleece construction
®
• Roloc quick-change system
• Diameter: 50.8 mm
• Recommended rpm: 8000–10000
• Max. rpm: 18000
9033-11-020/4 – – – – – 222834
Strip wheel set, 4-piece
Ideal for work on tough surfaces
• Soft variant
• Flexible coarse cleaning disc for universal cleaning
applications for use on larger surfaces
• Set consisting of 4 discs
• Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Open fleece structure
• Roloc quick-change system
®
• Diameter: 50.8 mm
• Recommended rpm: 8000–10000
• Max. rpm: 18000
9033-11-030/4 – – – – – 222728
Replacement bristle grinder set, purple, 2 pieces
Ideal for cleaning and gentle deburring
• Enables consistent results and cleaning effect throughout the
entire service life as no pressure is applied when working
®
• Roloc quick-change system allows the plastic brush to
9033-11-015 be changed quickly and easily without any extra tool
• Disc can be loosened and tightened at
the base plate by simple twisting
• Solid plastic brush offset with ceramic grit
• Adapts to contours and shape of the workpiece
• Bristle length: approx. 16 mm
• Max. rpm: 25000
• Diameter: 50 mm
9033-11-020/4 9033-11-030/4 9033-11-036/2 • Grain size: 36
9033-11-036/2 – – – – – 222872
Replacement bristle grinder set, green, 2 pieces
Ideal for cleaning and gentle deburring
• Enables consistent results and cleaning effect throughout the
entire service life as no pressure is applied when working
®
• Roloc quick-change system allows the plastic brush to
be changed quickly and easily without any extra tool
9033-11-050/2 9033-11-0120/2 9033-11-080/5 • Disc can be loosened and tightened at
the base plate by simple twisting
• Solid plastic brush offset with ceramic grit
• Adapts to contours and shape of the workpiece
• Bristle length: approx. 16 mm
• Max. rpm: 25000
• Diameter: 50 mm
9033-11-S 060
9033-11-S 080 • Grain size: 50
9033-11-0150/5 9033-11-0300/5 9033-11-S 120 9033-11-050/2 – – – – – 222865
