Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9033 Mini polisher set 9033 Right-angle grinder

• For working in areas with restricted access and / C
repair work
• 6-piece set, contents:
1 polisher
1 wet grinding pad, 75 mm x
1 soft plastic pad (yellow),
1 hard plastic pad (white),
1 lambskin
1 adjusting wrench
• Grinding disc thread M 6
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 96.76 db(A) Lp W
• Vibration acceleration: 2.43 m/s 2
• Power in watts: 238 watts 9233-010/5 9233-010/25 9233-011/10
• Cold insulated handle
1 l/min. rpm db (A) LpA 5 è 4
N
^
?
9033 N-7 113 12000 85 2000 – 205547
• Cut-off wheel set, 5 pieces
• For 9233-7 ∙ 9233-7/4
9233-010/5 – – – – 5 219063
• Cut-off wheel set, 25 pieces
• For 9233-7 ∙ 9233-7/4
9233-010/25 – – – – 25 219070
• Rough grinding wheel set, 10-piece
• For 9233-7 ∙ 9233-7/4
9233-011/10 – – – – 10 219087

9033 Angle grinder

• Extra flat grinding head – only 46 mm A/
1 l/min. rpm db (A) LpA 5 4 • Application: For working areas with restricted access,
N
^
?
9033 N-9 91 3200 85.76 720 205561 suitable for cutting metal sheet and steel
• 5 plastic pads yellow • Especially suitable for application in areas with restricted access,
e.g. cutting of exhaust pipe clamps when installed
hard, foam pad for polishing in the first work step • Reduced vibrations
9033-9-02/5 – – – 50 160556 • Quick adjustment (without tools) of protective cover
• 5 plastic pads white • Pressure key for locking the output (spindle locking)
soft, for polishing in the second work step enables easy changing of cut-off wheels
9033-9-03/5 – – – 80 160563 • Diameter of the wheel holder: 10 mm ( ⁄8")
3
• Lambskin 5 items • Including 1 cut-off wheel 100 x 0.8 x 9.53 mm
For 9033-9 • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
9033-9-04/5 – – – 80 160570 • Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
9033 Right-angle grinder • Sound power level: 100.5 db(A) Lp W
• Vibration acceleration: 3.65 m/s 2
• Lateral handle, to be used on left or right side • Power in watts: 700 watts
• Quick adjustment of protection cover without tools • Cold insulated handle
• For grinding discs up to a thickness of 0.8– 6 mm
• Spindle thread: M 14 x 2
• For grinding wheels 125 x 22 mm
• Spindle lock
• Air connection inlet: inside
thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal
size 7.2 (included)
• Hose diameter
(recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level:
96 db(A) Lp W
• Vibration acceleration:
6.50 m/s 2
• Power in watts: 671 watts
• Cold insulated handle

9033 P-08/25
B B
326 Valid until December 31, 2021 Components and spare parts from page 482 to 490
