Pneumatic Tools

Drilling and grinding machines

9033 Mini disc sander ∙ angled 9032 Carbide milling pin set 3 mm
C C C

1 l/min. rpm db (A) LpA 5 è 4 9032-03 KE 9032-03 KU 6 9032-03 ZY 6
^
N
?
Replacement bristle grinder set, white, 2 pieces 9032-03 KU 3 9032-03 ZY 3
Ideal for cleaning and gentle deburring
• Enables consistent results and cleaning effect throughout the 1 è 4
entire service life as no pressure is applied when working
®
• Roloc quick-change system allows the plastic brush to be • Set with 5 different milling cutters in cylindrical, tapered and spherical shape
changed quickly and easily without any extra tool • Head diameter (cylindrical shape): 3 / 6 mm
• Disc can be loosened and tightened at the base plate by simple twisting • Head diameter (spherical shape): approx. 3 / 6 mm
• Solid plastic brush offset with ceramic grit 9032-03/5 5 222483
• Adapts to contours and shape of the workpiece • Milling pin, cone-shaped
• Bristle length: approx. 16 mm 9032-03 KE – 226771
• Max. rpm: 25000
• Diameter: 50 mm • Milling pin, cone-shaped, x 3 mm
• Grain size: 120 9032-03 KU 3 – 226405
9033-11-0120/2 – – – – – 222858 • Milling pin, cone-shaped, x 6 mm
• 5 pieces Grinding pads, x 50 mm, 60 grain size 9032-03 KU 6 – 226764
• Base component: paper, Abrasive: resin, stearic acid metal salt • Milling pin, cylinder shape, x 3 mm
®
• Roloc connection 9032-03 ZY 3 – 226788
9033-11-S 060 – – – – 5 228287 • Milling pin, cylinder shape, x 6 mm
• 5 pieces Grinding pads, x 50 mm, 80 grain size 9032-03 ZY 6 – 226795
• Base component: paper, Abrasive: resin, stearic acid metal salt
• Roloc connection
®
9033-11-S 080 – – – – 5 228294 9032 Carbide milling pin set 6 mm
• 5 pieces Grinding pads, x 50 mm, 120 grain size
• Base component: paper, Abrasive: resin, stearic acid metal salt Made in Germany
• Roloc connection • Long service life and good cutting performance when used on diverse
®
9033-11-S 120 – – – – 5 228300 materials
• Suitable for hand-guided or stationary drive machines
9032 Carbide milling pin set 3 mm • According to DIN 8032
HAZET application tip:
Made in Germany – Use as high speeds as possible
• Long service life and good cutting performance when used on diverse – Contact surface between milling pin and workpiece should never
exceed 30 % of the complete milling circumference
materials
• Milling pin with 6 mm shaft
• Suitable for hand-guided or stationary drive machines • Working length: approx. 19 mm (cylindrical and cone-shaped)
• According to DIN 8032 • Set with 3 different milling cutters in cylindrical, tapered and spherical shape
HAZET application tip: • Head diameter (cylindrical shape): 10 mm
– Use as high speeds as possible • Head diameter (spherical shape): approx. 9 mm
– Contact surface between milling pin and workpiece should never
exceed 30 % of the complete milling circumference
• Milling pins with 3 mm shaft
• Working length: approx. 13 mm (cylindrical and cone-shaped)
• Set with 5 different milling cutters in cylindrical, tapered and spherical shape
• Head diameter (cylindrical shape): 3 / 6 mm
• Head diameter (spherical shape): approx. 3 / 6 mm

9032-06 KE 9032-06 KU 9032-06 ZY

9032-06 KE 9032-06 KU 9032-06 ZY
1 è 4

• Set with 3 different milling cutters in cylindrical, tapered and spherical shape
9032-03 ZY 6 9032-03 KE • Head diameter (cylindrical shape): 10 mm
• Head diameter (spherical shape): approx. 9 mm
9032-06/3 3 222667
• Milling pin, cone-shaped
9032-06 KE – 226825
• Milling pin, cone-shaped, x 9 mm
9032-06 KU – 226801
9032-03 KU 3 9032-03 KU 6 9032-03 ZY 3 • Milling pin, cylinder shape, x 10 mm
B 9032-06 ZY – 226818

Components and spare parts from page 482 to 490 Valid until December 31, 2021 331
