Pneumatic Tools Pneumatic Tools

Air blow tools Air blow tools

9040 Air blow gun 100 mm ∙ quiet 9040 Air blow gun 100 mm ∙ with
with bent pipe Venturi nozzle and bent pipe
• Extreme reduction of noise C
• Strong blowing force
• Non-blocking
• Application: Fast removal of shavings or other foreign objects,
especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood working, decor and in the home
• Pipe x: 8 mm
• Max. working pressure: 12 bar
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Blast pipe and shaft made of steel
• Spring made of hardened spring steel
• 2003/10/CE Max 85 dB
• OSHA 1910.95 (b) Max 90 dB 8 hr
• OSHA STD 1-13.1, Max 30 PSI if blocked
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
• Temperature range: -10°C – 80°C
1 K l/min. db (A) LpA 5 4
?
N
9040 P-4 265 235 83.7 165 209569
9040 Air blow gun ∙ quiet with wide flat nozzle

• Wide flat nozzle for cleaning surfaces
• Considerable blowing force
• Non-blocking
• Application: Fast removal of shavings or other foreign objects,
especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood working, decor and in the home
• Max. working pressure: 8 bar
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Spring made of hardened spring steel
• 2003/10/CE Max 85 dB
• OSHA 1910.95 (b) Max 90 dB 8 hr
• OSHA STD 1-13.1, Max 30 PSI if blocked
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
1 K l/min. db (A) LpA 5 4 • Temperature range: -10°C – 80°C
N
?
9040 P-3 255 245 76.8 100 209644

Air blow gun 100 mm ∙ with
9040 Venturi nozzle and bent pipe

• 100% increase in air outlet quantity thanks to Venturi nozzle
• Extreme blowing force
• Non-blocking
• Application: Fast removal of shavings or other foreign objects,
especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood working, decor and in the home
• Pipe x: 8 mm
• Max. working pressure: 16 bar
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Blast pipe and shaft made of anodised steel
• Spring made of hardened spring steel
• OSHA 1910.95 (b) Max 90 dB 8 hr
• OSHA STD 1-13.1, Max 30 PSI if blocked
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
• Temperature range: -10°C – 80°C

1 K l/min. db (A) LpA 5 4
N
?
B 9040 P-5 203 450 78 95 209576
336 Valid until December 31, 2021 Components and spare parts from page 482 to 490
