Pneumatic Tools Pneumatic Tools

Pneumatic adaptors Pneumatic adaptors

9045 Soda spray gun

• Does not damage rubber, glass or plastic parts
• No heating / deformation of sheets during blasting
• Application: Mineral spray gun for gentle, damage-
free and environment-friendly cleaning and removal
of paint with NaHCO3 (sodium bicarbonate)
• Application fields:
– Removing graffiti
– Facade and monument cleaning
– Removing paint from wooden objects
– Removing paint on glass surfaces and window frames
without causing damage to glass and seals
– Removing boot coatings, without attacking hull
• 1 preset metal precision nozzle for optimum performance
• 3 high performance wide-jet nozzles
• Refillable container with 1.2 l volume
• Including 1 kg soda blast-cleaning agent
• Working pressure: 6-12 bar
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Spring made of hardened spring steel
• Container made of PEHD
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6

9045 P-5 S
1 K l/min. 5 4
?
9045 P-1 247 280 460 209590
• Soda blast-cleaning agent consists of sodium bicarbonate
• Application
– material-friendly removal of paints, contaminants, etc.
– Stripping of car body parts and cleaning of components
careful removal of graffiti as well as for facades and cleaning landmarks
– Cleaning mouldings and extruder tools
• In a practical 5 l canister with carrying handle
• Optimal flow properties
• Angular powder with medium grain size ~ 25 μm³
9045 P-5 S – – – 210404

Pneumatic adaptors

9040 Spiral hose 9040 Spiral hose

• Polyurethan • High flexible polyurethane hose with length of 7.62 m and 10 mm inside x
• Length: 7.62 m
• Inside x: 6.35 mm • 360° swivel joint at the connecting pieces
• Connecting pieces with 360° swivel joints • Burst pressure according to DIN: 60 bar
• Burst pressure according to DIN: 55.1 bar / 800 PSI • Working pressure: 10 bar
3
• Working pressure: 10 bar • Air inlet thread: ⁄8″
• Air connection inlet: inside thread (IG) • Working length: 50% to 80% of the hose length
12.91 mm ( ⁄4″), coupler plug 7.2 mm type 1 • 100% silicone-free EPDM VK60FA
1
(DE/AT/SI/HU/CN/IN/PT/RU/PL/RO/TR) • Maximum flexibility
• Air connection outlet: outside thread (AG) • Highly abrasion-resistant
12.91 mm ( ⁄4″), coupler bushing 7.2 mm type 1 • Dimensional stable
1
• Coupler plug: Nominal size 7.2 (included) • Length: 7.62 m
• Hose inside x: 10 mm
• Air connection inlet: inside thread (IG)
1
12.91 mm ( ⁄4″), coupler plug 7.2 mm type 1
(DE/AT/SI/HU/CN/IN/PT/RU/PL/RO/TR)
• Air connection outlet: outside thread (AG)
12.91 mm ( ⁄4″), coupler
1
bushing 7.2 mm type 1
• Coupler plug: Nominal
size 7.2 (included)
• Temperature range:
-20°C – 60°C

1 5 4 1 K 4
9040-7 630 153404 9040 S-10 7.6 212361
340 Valid until December 31, 2021 Components and spare parts from page 482 to 490
