Pneumatic Tools

Air blow tools

9040 2-way air blow gun 9040 Blow pen

• Choice of air supply at tool head or handle S • Practical and compact design with clip for fixation e.g. in pockets S
• Application: Fast removal of chips or other foreign objects • Turn to adjust air flow
• Exchangeable nozzles: • Nozzle: 3 mm x
– Short nozzle for areas with restricted access • Easy handling, clicks directly on air coupling 7.2 mm
– Long nozzle (112 mm) with safety nozzle tip (scratch protection) • Inlet pressure: 12 bar
• Maximum pressure: 10 bar • Max. airflow at 6 bar: 360 l/min
• Pressure regulator • Perbunan seal (NBR)
• To be used on machinery, in workshops, for wood working, decor and in the home • Duraluminium housing
• Aluminium housing • Coupler plug: integrated, nominal size 7.2
• Thread nozzles: /8 inch PF 28
1
(9.728 mm outside x / 0.907 mm pitch)
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6.3
• Anti-slip, cold insulated handle

360°

1 4
9040-3 109500

1 l/min. db (A) LpA 5 4
N
?
9040-4 330 86 205 176236
9040 LG Air blow gun ∙ long

• With 90° side nozzle and Venturi nozzle S
• Application: Cleaning areas with restricted access on vehicles, machinery and
agricultural machinery
Especially suitable for cleaning cooling fins
• Grip area with insulated lance to protect it from cold
• Increased efficiency due to Venturi nozzle (54 mm / 35 gram)
• 90° side nozzle (32 mm / 8.4 gram) for cleaning cooling fins
• Maximum pressure: 12 bar
• Ergonomic handle
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Cold insulated handle

1 K l/min. 5 è 4
?
9040 Lg-3/2 1085 450 313 2 206339
