Pneumatic Tools

Pneumatic adaptors

9040 Hose reel 9040 Hose reel

• Hose stop at any point with “Stop at any point” function • Hose stop function possible at any point with “Stop at any point”
• Neat winding of the hose thanks to automatic guidance • Neat winding of the hose thanks to automatic guidance
• Braked winding to prevent risk of accidents • Braked winding to prevent risk of accidents
• Suitable for compressed air or water • Suitable for compressed air or water
• Dimensions: 459 x 378 x 205 mm • Dimensions: 500 x 418 x 210 mm
• Dimensions (packed): 465 x 400 x 220 mm • Hybrid polymer hose, black
• Hybrid polymer hose, black • Inside diameter of the hose: 13 mm ( ⁄2″)
1
• Inside diameter of the hose: 10 mm • Hose length: 15 m
• Hose length: 15 m • Length of connection hose: 1 m
• Length of connection hose: 0.9 m • Max. working pressure: 20 bar
• Max. working pressure: 20 bar • Integrated drill template for mounting on cardboard packaging
• Integrated drill template for mounting on cardboard packaging • Meets all relevant requirements defined in the European
• Meets all relevant requirements defined in the European Directives for Machinery 2006/42/EC
Directives for Machinery 2006/42/EC • Closed special plastic case, supplied with rotating metal
• Optionally usable with HAZET safety coupling 9000-061 mounting bracket made for separate installation at the workplace
• Closed special plastic case, supplied with rotating metal mounting Borehole spacing of the mounting bracket: 186 mm
1
bracket made for separate installation at the workplace • Air connection inlet: Outside thread 20.96 mm ( ⁄2″)
1
• Borehole spacing of the mounting bracket: 186 mm • Air connection outlet: Outside thread 20.96 mm ( ⁄2″)
3
• Air connection inlet: outside thread (AG) 16.41 mm ( ⁄8″) • Temperature range: -40°C – 80°C
3
• Air connection outlet: outside thread (AG) 16.41 mm ( ⁄8″)
• Automatic hose reel offers tidiness in the workshop – hose not
left lying around, thus reducing the risk of accidents

1 K 5 4
9040 N-13 15 9500 214648

1 K 5 4
9040 N-10 15 6450 206445

Components and spare parts from page 482 to 490 Valid until December 31, 2021 341
