Page 343 - HAZET英文2021

Pneumatic Tools Pneumatic Tools

Pneumatic adaptors Pneumatic adaptors

9000-040 Rotary joint with continuous 9000-010-014 Air inlet nipple set
air flow rate reducer
C
• Maximum pressure: 16 bar 1 5 è 4
• Release of the rotating function through compressed
air supply, rigid in unpressurised condition • Used in Belgium, France, Netherlands, Switzerland
• 12.91 mm / ⁄4″ thread IG (inside thread)
1
• 12.91 mm / ⁄4″ thread AG (outside thread) • Orion type
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) 9000-011/3 16 3 195022
1
• Air connection outlet: outside thread (AG) • Used in Arab countries, Italy, Spain
12.91 mm ( ⁄4″) 9000-012/3 20 3 195237
1
• 360° rotatable • Used in Israel / USA
hinge on 2 axes 9000-013/3 20 3 198139
• Air flow regulation by
means of setting wheel • Used in Japan, China, Korea
9000-014/3 20 3 198160
2162 Mini grease gun
1 5 4 • Filling capacity: 80 g
• Creates pressure up to
9000-040 88 195350 1,000 PSI / 69 bar
• Filling with loose grease
• Including lubricating nipple
9000-041 Rotary joint in 50° and 90° versions

• Pneumatic rotary joint can be rotated 360°
• Sealing material: NBR
• Maximum pressure: 16 bar
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Air connection outlet: outside
thread (AG) 12.91 mm ( ⁄4″)
1
• Surface: nickel-plated

1 5 4
9000-041 72 204441
9300 N-60
9000-010-014 Air inlet nipple set
1 4
• Adaptation of country-specific connection standards to HAZET pneumatic K
tools
2162 M 145 185634
• 12.91 mm / ⁄4″ thread • Rapid and clean filling of the HAZET 2162 M mini grease gun
1
• Steel, nickel-plated • Improved mechanical stability prevents loss of lubrication
• Design with sealant on the thread performance in vibrating environment
• Air connection inlet: coupler plug 7.2 mm type 1 (DE/ • Good water washout resistance
AT/SI/HU/CN/IN/PT/RU/PL/RO/TR) • High oxidative stability
• Air connection outlet: outside thread (AG) 12.91 mm ( ⁄4″) • High corrosion protection and excellent adhesion on metallic surfaces
1
• Surface: nickel-plated • Grease cushion 60 ml
9300 N-60 – 203406
9000-020-022 Hose connection nipple set

• Adaptation of country-specific connections to
compressed air hoses
• Hose clip: 10 mm x
9000-011 9000-012
• Steel, nickel-plated
• Air connection inlet: coupler plug 7.2 mm type
1 (DE/AT/SI/HU/CN/IN/PT/RU/PL/RO/TR)
• Air connection outlet: hose nipple x 10 mm
• Surface: nickel-plated
• Used in Germany (standard), Austria, Slovenia, Hungary,
China, India, Portugal, Russia, Poland, Romania, Turkey
9000-013 9000-014
1 5 è 4

• Used in Germany (standard), Austria, Slovenia, Hungary,
China, India, Portugal, Russia, Poland, Romania, Turkey 1 5 è 4
9000-010/3 17 3 195015
B 9000-020/3 17 3 195244
342 Valid until December 31, 2021 Components and spare parts from page 482 to 490
