Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9034 P Sabre saw 9035 Needle scaler

• Increased efficiency with reduction of weight, air consumption, noise • Pistol shape A/
generation and vibration
• Adjustable needle cover enables maximum utilisation of needles
• Direction of air exhaust adjustable • Two-piece housing design for easy maintenance
• Suitable for cutting small radii • 19 needles, x 3 mm
• Cutting capacity aluminium: 4 mm • 3,200 impacts/min
• Cutting capacity sheet steel: 3 mm • Air connection inlet: inside thread
1
• Strokes/min.: 9500 (IG) 12.91 mm ( ⁄4″)
• Particularly suitable for cleaning sensor modules etc. • Coupler plug: Nominal
due to file blade socket (included in delivery) size 7.2 (included)
Contents: • Working pressure (bar): 6.3
1 sabre saw • Cold insulated handle
3 saw blades, 18 / 24 / 32 teeth each (overall length: 93 mm)
1 reciprocating saw blade, 18 teeth (overall length: 153 mm)
5 files (overall length: ~135 mm)
1 inside hexagon socket wrench (in the handle)
• Air connection inlet: inside
1
thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal
size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 97.7 db(A) Lp W
• Vibration acceleration: 6.13 m/s 2
• Saw stroke: 10 mm

9035-050
1 l/min. db (A) LpA 5 4
N
?
9035-5 170 97 2600 132355
Spare needles
For needle scaler 9035-5
19 needles, x 3 mm
9035-050 – – 202 139385
9034 P-018/5
9034-024/5
9034 P-R/5 9034 P-050/5 9034-032/5 9035 Needle scaler
1 K l/min. db (A) LpA 5 4 • Extremely slim / short pin form and free needles allow you to reach difficult
N
?
to access areas as well.
9034 P-2 160 99 86.7 400 218288 • 28 mm slim handle guarantees best haptics
Reziprok sabre saw blades • 235.6 mm short device even reaches restricted spaces
suitable for sabre saw 9034 P-2 • 13 thin needles (x 1.3 mm) ensure damage-free
• 5 pieces per package processing and highly fine surface structure
• Bevelled, corrugated teeth, 18 teeth • Powerful and efficient tool
• For all metals including non-iron pipes, sheets and • Only 480 g – very lightweight and easy to handle
stainless steel, material thickness 1.5 – 3 mm • 3000 impacts/min
• Total length: 153 mm • Safety lever
• Bi-metal • Infinite adjustable power
9034 P-R/5 153 – – 175 218318 • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
File set • Coupler plug: Nominal size 7.2 (included)
suitable for sabre saw 9034 P-2 • Working pressure (bar): 6.3
• 5 pieces per package • Sound power level: 98.8 db(A) Lp W
• Contents: • Cold insulated handle
1 round file
1 triangular file
1 half-round file
1 flat file
1 square file
• Suitable for numerous materials
• Total length: approx. 135 mm
9034 P-050/5 135 – – 115 218349
• Saw blades
suitable for 9034-1 ∙ 9034 P-1 ∙ 9034 P-2 sabre saws
• 5 pieces per package
• 93 mm total length
• Socket 1 x 13 mm
• 18 teeth
9034 P-018/5 93 – – – 225958
• 24 teeth
9034 P-024/5 93 – – – 225965
• 32 teeth 9035 M-050
9034 P-032/5 93 – – – 225989 B
332 Valid until December 31, 2021 Components and spare parts from page 482 to 490
