Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9033 Orbital sander 9033 Belt sanders

• Dust extraction A/ C
• Suction hose (2.0 m) and collection bag included
• Continuous speed regulation
• Low height and light composite housing
• Grinding disc with 15 bore holes, x
150 mm with hook and loop fastener
• Anti-slip handle
• Air connection inlet: inside
thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size
7.2 (included)
• Working pressure (bar): 6.3
• Stroke: 5 mm
• Power in watts: 375 watts

1 l/min. rpm db (A) LpA 5 4
N
^
?
9033 N-4 94 19000 83.8 810 210183
Abrasive belts
For belt sander 9033-4
1 l/min. rpm db (A) LpA 5 4 330 x 10 mm. Pack contents 10 pieces.
N
^
?
Grain size 80
9033-2 57 12000 88.8 900 156337 9033-480/10 – – – 39 139101
Grinding pads Grain size 100
For orbital sander 9033-1 and -2 9033-4100/10 – – – 35 139118
6 holes
For metalworking. x 150 mm. Grain size 120
Pack contents 10 pieces 9033-4120/10 – – – 32 139125
Grain size 80
9033-180/10 – – – 161 139330
Grain size 100 9033 Mini orbital sander set
9033-1100/10 – – – 133 139347
Grain size 120 • For working in areas with restricted access and repair work A/
9033-1120/10 – – – 139 139354 • 36-piece set, contents:
Grain size 150 – 1 orbital sander
9033-1150/10 – – – 123 139361 – 2 grinding discs 50 mm (2") and 76.2 mm (3")
– 10 grinding pads each, grain size 320 / 400 / 600
15-hole grinding disc – 1 Adjusting wrench
For Orbital sander 9033-2 • With hook and loop fastener
• Medium hard with fiber-reinforced rear side • Grinding disc thread: M 6
• With hook and loop fastener • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
5
• x 150 mm with ⁄16″ thread • Coupler plug: Nominal size 7.2 (included)
9033-020 – – – 170 156351 • Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
9033 Belt sanders • Sound power level: 93 db(A) Lp W
• Vibration acceleration: 0.77 m/s
2
• Power in watts: 238 watts
• Continuous speed regulation via speed regulator on back of handle • Cold insulated handle
• Application: For narrow surfaces (belt width 10 mm)
• Locking device for quick belt changing
• For abrasive belts 10 x 330 mm
• Automatic belt adjustment
• Fine adjustment of belt
• 360° rotatable belt run
• Belt speed: 1370 m / min
• Incl. hex-head wrench for fine adjustment of the
belt and angle setting in the handle
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 94.8 db(A) Lp W
• Vibration acceleration: 1.88 m/s 2
• Power in watts: 417.6 watts
• Cold insulated handle

B B
324 Valid until December 31, 2021 Components and spare parts from page 482 to 490
