Pneumatic Tools Pneumatic Tools

Drilling and grinding machines Drilling and grinding machines

9022 Air ratchet ∙ extra long

• Reaches even extremely hard to reach spaces and tolerates high manual retightening forces
3
• Application: Slim design, e.g. for the installation and removal of timing chain covers
• For manual retightening with torque values up to 400 Nm
• Reduced vibrations
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 104.7 db(A) Lp W
• Vibration acceleration: 5.60 m/s 2
• Forward and reverse: single-stage (right/left)
• Cold insulated handle

1 Y K l/min. rpm db (A) LpA 5 4
?
^
N
Nm
9022 P-X Lg 94.8 551 99.12 160 93.7 2100 222513
Drilling and grinding machines

9030 Drilling machine 9030 Angle drill
• Exhaust air is guided downwards through the handle A • For working in areas with difficult access A/

• Application: Practical tool especially for car body works and industry • Keyless drill chuck
• Tool-free quick-clamping drill chuck • Exhaust air is guided through the handle backwards
• Robust machine housing • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Suitable for continuous operation • Coupler plug: Nominal size 7.2 (included)
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) • Hose diameter (recommended): 10 mm
• Coupler plug: Nominal size 7.2 (included) • Working pressure (bar): 6.3
• Hose diameter (recommended): 10 mm • Sound power level: 96 db(A) Lp W
• Working pressure (bar): 6.3 • Vibration acceleration: 0.50 m/s 2
• Sound power level: 99.7 db(A) Lp W • Collet chuck: 1 – 10
• Vibration acceleration: 2.10 m/s 2 • Forward and reverse: single-stage (right/left)
• Collet chuck: 1 – 10 • Power in watts: 373 watts
• Forward and reverse: single-stage (right/left) • Cold insulated handle
• Power in watts: 373 watts
• Cold insulated handle

1 l/min. rpm db (A) LpA 5 4 1 l/min. rpm db (A) LpA 5 4
^
N
N
?
^
?
9030 N-1 113 2000 88.7 1000 206377 9030 N-5 113 1400 85 1200 205554
