Pneumatic Tools Pneumatic Tools

Air ratchet Air ratchet

9022 Impact ratchet 9022 Air ratchet

• Maximum occupational safety thanks to / 2 • Reduced vibrations / 3
reaction-free striking mechanism • Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
1
• Low-impact • Coupler plug: Nominal size 7.2 (included)
• Rubber ratchet head protective cover to protect against shocks and • Working pressure (bar): 6.3
penetration by dirt • Sound power level: 95 db(A) Lp W
• Vibration acceleration:
• Application: Use in constricted spaces 8.50 m/s 2
• For hand retightening with torque values: 260 Nm • Forward and reverse:
• Powerful twin hammer mechanism single-stage (right/left)
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″) • Cold insulated handle
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 93 db(A) Lp W
• Vibration acceleration: 9.84 m/s 2
• Forward and reverse: single-stage (right/left)
• Cold insulated handle

1 Nm l/min. rpm db (A) LpA 5 4
^
Y
N
?
9022-2 70 180 160 88 1200 109456
• For hand retightening with torque values > 400 Nm
/ 3
• Completely closed head avoids the entry of swarf etc.
• Reduced vibrations
1
• Air connection inlet: inside thread (IG) 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 110 db(A) Lp W
• Vibration acceleration: 9.10 m/s 2
• Forward and reverse: single-stage (right/left)
• Cold insulated handle

1 Y K l/min. rpm db (A) LpA 5 4
^
N
?
Nm
9021 SR-1 68 158 68 500 82 670 218295

1 Y l/min. rpm db (A) LpA 5 4
^
N
?
Nm
9022 P-2 108 113 280 99 1240 184538
318 Valid until December 31, 2021 Components and spare parts from page 482 to 490
