Pneumatic Tools

Impact wrench

9013 TT Twin Turbo impact wrench 9014 TT Twin Turbo impact wrench
C C
4 5

1 Ú Nm l/min. rpm db (A) LpA 5 4
^
Y
?
N
Nm
9014 TT 4100 2170 235 5200 101.9 4600 234684
9014 P Impact wrench
• Loosening torque: 3400 Nm
9040-013 5
• Exhaust air is guided through the handle downwards
• Reduced vibrations
• Easy handling
• Direct hammer striking mechanism
• Air connection inlet: inside thread (IG) 20.67 mm ( ⁄2″)
1
• Coupler plug: nominal size 10 (included)
• Recommended torque: 2400 Nm
• Hose diameter (recommended): 19 mm
1 Nm Nm l/min. rpm db (A) LpA 5 4 • Working pressure (bar): 6.3
Ú
^
N
?
Y
• Sound power level: 114.5 db(A) Lp W
9013 Lg TT 3800 2020 243 5200 102.5 5500 232277 • Vibration acceleration: 15.94 m/s 2
Low noise hose for noise reduction of the HAZET Twin Turbo impact wrenches • Loosening torque (max) determined with screw size M: 36
9013 TT ∙ 9013 Lg TT • Forward and reverse: three-stage (forward and reverse)
Spring clamp for fixing the hose to the handle • Cold insulated handle
9040-013 – – – – – – 232994 • Output designed with hole for pinning as well as a nut-driver holder ring
• Operation optimised on both sides for left and right handed users
• One-hand reversing switch
9014 TT Twin Turbo impact wrench • Extremely powerful tool
• Optimised feel
• Loosening torque: 4100 Nm • Air inlet possible on the handle at the bottom and rear
5
• Exhaust air is guided through the handle downwards
• Reduced vibrations
• Easy handling
• Short, compact design
• One-hand operation for left and right handers
• Removable handle, 360° adjustable
• Connecting socket for low noise hose
• HAZET Twin Turbo technology – high torques with compact design
• Innovative 8-blade air motor with 25% higher impact
performance ensures maximum torques
• Powerful twin hammer mechanism
3
• Air connection inlet: inside thread (IG) 16.41 mm ( ⁄8″)
• Coupler plug: Nominal size 7.2 (included)
• Recommended torque: 1898 Nm
• Hose diameter (recommended): 13 mm
• Working pressure (bar): 6.3
• Sound power level: 112.9 db(A) Lp W
• Vibration acceleration: 19.11 m/s 2
• Loosening torque (max) determined
with screw size M: 32
• Forward and reverse: two-stage
(forward), single-stage (reverse)
• Cold insulated handle

1 Nm Y l/min. rpm db (A) LpA 5 4
Ú
^
N
?
Nm
B 9014 PS-1 3400 2712 283 5500 103.5 7800 222490
Components and spare parts from page 482 to 490 Valid until December 31, 2021 315
