WHEEL ALIGNMENT: SERVICE TOOLS
UNDERCAR

GCP10 GAW1290 TC90A B240B
S6229

BF620C BF623 WAGM1A
YA6510
YA6510-2
General Service Tools
GCP10 Grease and Dust Cap Tool YA6510-2 Bushing Extractor Adaptor (Blue-Point )
®
• Tapered jaws of the tool fit behind the crimped edge of • Enables the YA6510 Bushing Extractor to be used on
®
the grease cap 1990–1993 Integra vehicles
• One handle is designed for prying hub caps loose BF620C Rubber Head 11ʺ Mallet (Blue-Point )
®
GAW1290 Wheel Alignment Wrench • Solid-rubber head is 3-3/4ʺ long, 2-1/4ʺ dia
• 18-1/2ʺ long for extra leverage • 11ʺ hardwood handle
• 21 mm 12-point with special angle and bidirectional BF623 Soft Blow 12-1/2ʺ Mallet (Blue-Point )
®
offset to access difficult-to-reach bolts • Designed to reduce marring and denting
• 24 mm 12-point deep offset for access to guarded • For use in assembly applications and on all types of
bolt heads without the sloppiness of a breaker bar surfaces, including metal, glass, plastic and wood
and socket • Special polymer head resists dynamic fatigue, creep and
• 24 mm 12-point deep offset for access to 12-point bolt compression set, even at extreme temperatures
heads with access to the lock nuts through the socket • Conforms to irregular surfaces
®
®
• Used on alignment bolts for Audi , VW , Porsche , • Dissipates hand-jarring shock
®
®
BMW and MINI vehicles • Resists most chemicals
®
TC90A ‡ Tailpipe Cutter (Blue-Point ) • Wood handle
®
• Handles cutting from 3/4–3-1/2ʺ dia WAGM1A Alignment Tool for GM Vehicles
®
• 16-link cutter chain is 12ʺ long • Updated drive location allows for increased access
• Threaded shaft with crosspiece provides elasticity to away from the vehicle’s frame
help prevent the chain wheels from breaking • 1/2ʺ square drive allows for better leverage
• Ideal for cutting the strut assembly to enable servicing of • Robust design and rugged construction for better
the strut cartridge engagement on the alignment cam
TC90A1 ‡ Chain Assembly (Blue-Point ) S6229 Steering Rack Spanner Socket
®
• Includes one wheel and one roll pin • Allows the steering rack to remain in the vehicle for
®
B240B Brake and Accelerator Pedal Jack (Blue-Point ) repairs without using a screwdriver and hammer
• Holds throttle at a constant RPM • Removes and installs the cylinder end stopper on
• Easily adjusts to desired length 2004–2009 Lexus RX330 and RX350 vehicles and
®
®
®
• Adjustment screw fine-tunes desired RPM 2004–2007 Toyota Highlander vehicles
• Rubber tip keeps the tool firmly positioned • 3/8ʺ drive and designed specifically for this application;
• Overall length of 40ʺ (102 cm) will not mar or damage the cylinder
• Can also be used as a pedal depressor • Manufactured from special-alloy steel and heat treated
YA6510 Bushing Extractor (Blue-Point ) for optimum strength and durability
®
®
• Used on 1994–2001 Acura Integra plus various • Tool is industrial finish but is not impact rated, as it is for
®,
1988–2001 Honda vehicles hand tool use only
®
SHOCK ABSORBER
Shock Absorber Sockets
Stock No. Square Drive, inches Wrench Oval Diameter Wrench Oval Width Length, inches
A137 3/8 5/16ʺ 1/4ʺ 29/32
A137
A138 3/8 21/64ʺ 15/64ʺ 29/32
A139 3/8 8 mm 6 mm 0.9
CASTER CHAMBER
Caster/Camber Tools
Metric combination wrenches. Long handle design for access.
CC6630 Caster/Camber Alignment Tool • Hook tool on the top A arm and, with
• Eliminates the need to use the front 21 mm locking nut loosened, push or pull for easy
CC6630 eccentric bolt, which is difficult to access caster and camber adjustment
behind a steel shield • Saves about 15 minutes per side
