Ball Joint Presses
ME7A207 Retaining Ring ME9A34 Steel Ball ME7A208A Large ME7A209A Small
• Retaining ring included in • Steel ball included in the Snap Ring Snap Ring
the BJP1 and UJP1 sets BJP1 and UJP1 sets • Large snap ring included • Small snap ring included
in the BJP1 and UJP1 sets in the BJP1 and UJP1 sets

Ball Joint Sockets
S9365B Ball Joint Socket WHEEL ALIGNMENT: BALL JOINT UNDERCAR
®
• For medium-size Chrysler cars
• 3/4ʺ square drive
• 1-59/64ʺ wrench size; 2ʺ long
S9479A Ball Joint Socket
®
®
• For Dodge /Chrysler pickups and vans S9365B S9479A
• 3/4ʺ square drive
• Wrench size is 2-9/64ʺ, length is 2ʺ
S9613 Ball Joint Socket
• For use on 4-5B axles found on Dodge , Ford , Chevrolet ,
®
®
®
®
GMC and International 4-wheel drive trucks
®
• Adjusts the sleeve in the top of the yoke on the
front suspension
• 1/2ʺ square drive, 1ʺ O.D.; 2-1/8ʺ long; S9613
BJR1 Ball Joint Socket (Subaru vehicles)
®
• Easily removes stubborn ball joints on Subaru 2003–2006 BJR1 BJR2
®
Baja , 1998–2010 Forester , 1993–2010 Impreza, 1990–2010
®
®
Legacy and 2000–2010 Outback models
®
• Stay safe dealing with low clearance and heavy corrosion
• Beat the flat rate by doing the job faster and with less effort
BJR2 Ball Joint Socket (Subaru vehicles)
®
• Faster, safer ball joint removal for Subaru vehicles
®
• Easily removes stubborn ball joints for increased
productivity
• 3/4ʺ hex on the pressure screw can be driven by hand or A204 A200
with an impact gun
• Industrial finish helps protect against corrosion Ball Joint/Tie Rod Separators
®
• For use on 2006–2012 Subaru Tribeca vehicles
Stock No. Jaw Opening, inches Overall Length, inches
A204 5/8 12
A200 13/16 18
A201 1 12
A203 1-1/4 12
SERVICE TOOLS
General Service Tools
®
YA7970 Hub Clamp Expander (Blue-Point )
• Designed for hubs, and clamping-style struts and ball joint mounts
• Allows easy removal and installation of struts and ball joints
• Interchangeable spreaders prevent damage to aluminum or cast iron hubs
• Adjustable for use on hubs with a centralized or non-centralized slot
• Allows for on-vehicle repair
Emergency Brake YA7970
SIML160 1/2ʺ Drive 6-Point SAE 1/2ʺ Flank Drive Extra-Deep Impact Socket
®
• Used to remove or replace fuel tank retaining strap nuts
• Other applications include emergency brake adjustment nuts and stabilizer retainers
• 1/2ʺ square drive; 1/2ʺ; 6-point wrench opening
• 5ʺ long
SIML180 1/2ʺ Drive 6-Point SAE 9/16ʺ Flank Drive Extra-Deep Impact Socket SIML160 SIML180
®
• Same design as SIML160, except hex size is 9/16ʺ
697
• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
