TIRE AND WHEEL: SHACKLE PIN
UNDERCAR
Shackle Pin Impact Sockets SPS12 1/2ʺ Drive SAE 3/4 x 1-9/32ʺ
Designed with an oval configuration to Shackle Pin Impact Socket
®
®
service shackle pins on International • For use on Freightliner 120 Series and
®
and Kenworth semitrucks. trucks with newer large spring bolts
SPS10A 1/2ʺ Drive SAE 41/64ʺ Shackle • Impact rated 1/2ʺ drive
• Socket opening is 3/4 x 1-9/32ʺ;
Pin Impact Socket
SPS10A 1-3/4ʺ long
• Designed with an oval configuration to
®
service shackle pins on International SPS13 Spring Shackle Pin Socket
®
and Kenworth semitrucks • Used to remove and install spring
SPS13 SPS11A 1/2ʺ Drive SAE 21/32 x 1-17/32ʺ shackle pins on front suspensions of
Volvo truck and VN420/610/660/770
®
Shackle Pin Impact Socket Daycab vehicles
• Socket opening is 21/32 x 1-17/32ʺ; • Hardened pins for engaging the
1-3/4ʺ long shackle pin
LUG/RETAINING NUT

HDLUGSET2 S6840
Heavy-Duty Truck Wheel Lug Sockets Lug Nut Removal Sockets, Magazine Loading
HDLUGSET1 Heavy-Duty Lug Socket Set S6840 Magazine Loading Lug Nut Removal Socket
• Includes SIM383, SIM403, SIM483B, SIMM333, • Flank Drive wrenching system grips the fastener on the
®
SIMM383, plus BW726A and BWD483 flanks/flats to increase torque and prevents the fastener
• Flank Drive wrenching system from rounding, increasing the life of the socket
®
• Alloy steel combines strength and durability • Saves the technician time by housing the five lug nuts
• All sockets are 1ʺ square drive as they are removed—one at a time—from the wheels on
®
HDLUGSET2 Heavy-Duty Lug Socket Set Flexi-Van chassis trailers
• Includes SIM342, SIM482, SIMM332, SIMM382,
SIMM412 and DW402C, plus BW626A, BWD482 and
BWDM412 in a PAKPB063 Storage Case
®
• Flank Drive wrenching system
• Alloy steel combines strength and durability
• All sockets 3/4ʺ square drive
TIRE AND WHEEL: BUDD WHEEL

Budd Wheel
Impact Sockets
• 6-point and square
openings are
combined
• For use with the socket
retainers listed below BWD482 BWDM412 BWDS483
• Industrial finish
A, Socket End B, Drive End D, Length, E, Hex Depth, F, Square Hex Size, Square Size, Square Drive,
Stock No.
Diameter, inches Diameter, inches inches inches Depth, inches inches inches inches
BWD482 2-7/32 1-3/4 4 5/8 1-11/16 1-1/2 13/16 3/4
BWD483 2-15/64 2-15/64 4 5/8 1-11/16 1-1/2 13/16 1
BWDM412 2-11/32 1-3/4 4-1/4 17/32 1-43/64 41 mm 21 mm 3/4
BWDS483 2-15/64 2-15/64 4 5/8 1-9/64 1-1/2 13/16 1
BW630 1-13/32 1-5/8 2-1/4 1-9/64 — — — 3/4
BWDM412 3/4ʺ Square Drive 6-Point Metric 21 mm Square Budd Wheel Impact Socket
• For 1986–later Nissan and Isuzu Class 4, 5, 6 and 7
®
®
• Impact sockets are heat treated to a low hardness range compared to chrome sockets so that under heavy, continuous
use, the impact socket will withstand the impact blows and wear rather than break
BWDS483 1ʺ Square Drive 6-Point SAE 13/16ʺ Square Budd Wheel Impact Socket
• Dual-opening socket allows for just one socket to remove the outer hex nut and the inner square nut used on Budd wheel
assemblies for semi trucks and buses
®
• Flank Drive wrenching configuration
• Special alloy steel for strength and durability
• The BWDS483 is designed to engage short inner nuts only; use the BWD483 for long inner nuts
