TIRE AND WHEEL: AXLE NUT SOCKETS
UNDERCAR

Retaining Nut Sockets
S8695C Axle Nut Socket 4 Lug S6146 1/2ʺ Square Drive S6109A Axle Nut Socket
• 1/2ʺ square drive; 3-3/4ʺ long Axle Nut Socket 6 Lug
• For 1/2-ton vehicles with manual 4 Lug • Used for the front wheel
locking nuts
S8695C • For use on the front wheel bearing • Used for the front wheel bearing retaining nut on
3/4-ton vehicles with
bearing retaining nut on
®
retaining nut on a Dana 44 Series 3/4-ton vehicles with heavy-duty suspension
®
axle used on 1959–later GM , Ford , a Dana 60 Series axle • Designed for use on GM ,
®
®
®
Dodge and AMC ® used on GM , Ford and Ford and Dodge trucks
®
®
®
®
®
• Industrial finish Dodge trucks with a Dana 70 Series axle
®
®
• Railroad applications: Used to
S6146 install or remove the point detector • 3-3/4ʺ long • 1/2ʺ square drive;
3-3/4ʺ long
• Industrial finish
bushing found on WABCO-M23B • Industrial finish
switch machines
S6109A
SPANNER SOCKETS
Spanner Sockets
®
®
For use with a torque wrench when servicing Chevrolet , GM and Ford axles
®
Square Drive, Outside Dia.,
Stock No. No. of Lugs Applications
inches inches
®
ANS1929A* 3/4 6 2-5/8 Chevy /GMC with 5,200 and 7,200 lb Axles
®
ANS1930 3/4 6 2-7/8 Chevy /GMC with 11,000 and 13,500 lb Axles
®
®
ANS7269A 1/2 4 2-3/4 1985–later Ford F-250/F-350 with floating Rear Axle
®
ANS1929A
*Blue-Point
TIRE AND WHEEL: SPINDLE NUT SOCKETS
SNS2467 SNS2770

YA6540
SNS3195 SNS3246
SPindle Nut Sockets SNS3195 Spindle Nut Axle Lock Nut Removers
®
SNS2467 Spindle Nut Socket (Blue-Point ) YA6540 Nut Remover Kit for Toyota /
®
Socket (Blue-Point ) • For high-shear Lexus Vehicles Axle Locks
®
®
rotating nuts
• Removes and installs • 1/2-ton Dana 80 axle • Prevents damage to the axle shaft threads when
®
four-slot axle lock nuts • Socket I.D.: 2-3/8ʺ removing the lock nut
• 1/2–3/4-ton Dana • 1/2ʺ drive • Unlocks and removes the 30 mm axle nuts from Toyota /
®
®
44 axle Lexus vehicles
®
• Socket I.D.: 2ʺ SNS3246 Socket, Spindle • Kit combines a 1/2ʺ drive 12-point special depth 30 mm
• 1/2ʺ drive Nut, 4 Lug, 4 Wheel Drive impact socket and a unique angle axle-nut release tool
®
SNS2770 Socket, Spindle (Blue-Point ) YA6541 1/2ʺ Drive 30 mm Impact Socket (Blue-Point )
®
®
Nut, 6 Lug, 4 Wheel Drive • Removes and installs YA6542 Lock Nut Release Tool (Blue-Point )
four-slot axle lock nuts
®
(Blue-Point ) • 3/4–1-ton
• Removes and installs • Socket I.D.: 2-1/4ʺ
four-slot front axle • 1/2ʺ drive
lock nuts
• 3/4–1-ton Dana 44 axle
®
• Socket I.D.: 2-1/4ʺ
690 • 1/2ʺ drive
