TIRE AND WHEEL: BUDD WHEEL

Stud Remover and Installers
®
WSK12 Stud Installer/Rethread Kit (Blue-Point )
• Self-centering units permit quick installation
the first time
• Helps eliminate damage to threads
• Designed for use with an impact wrench
• Set replaces both the WSK755 and WSK938 sets UNDERCAR
• Packaged in a blow-molded box for easy storage BWS1316A
®
BWS1316A Stud Remover (Blue-Point )
• Use on 13/16ʺ studs on Budd wheels
WSK12

Impact Sockets
• For use with the socket retainers listed below
• Industrial finish
®
• Snap-on impact sockets are heat-treated to a lower hardness to add impact resistance and ductility
• Superior wall construction absorbs repeated impact cycling loads
®
• Flank Drive wrenching system provides flat-to-flat contact for up to 20% more turning power BW626A
• 6-point sockets engage fasteners every 60˚ for better turning power
• Always use impact sockets with impact guns to prevent injury and socket damage
Stock No. Square Drive, inches Wrench Size Length
BW626A 3/4 13/16ʺ Square 4ʺ
IM562 3/4 1-3/4ʺ Hex 2-3/4ʺ
SIMM332 3/4 33 mm Hex 82.6 mm
BW726A 1 13/16ʺ Square 2-1/4ʺ
SIMML332 3/4 33 mm Hex 152.4 mm
SIMML333 1 33 mm Hex 152.4 mm

IMPACT SOCKET RETAINERS

IMR3
IM182P
3/4ʺ Drive Impact Socket Retainers IM182R
Stock No. Description Square Drive, inches
IM182P Steel Locking Pin 3/4
IM182R Rubber Locking Ring 3/4
IMR2 Socket Retainer 3/4
IMR3 Socket Retainer 1ʺ Spline

TIRE AND WHEEL: GENERAL SERVICE TOOLS

®
®
Toyota /Lexus Carrier Assembly Socket
B2193 3/8ʺ Drive 5-Point Spare Tire Carrier Assembly Socket
• Tough nickel-chrome plating provides corrosion resistance
• Special-alloy steel provides the highest match of strength and durability
®
®
• Lower and remove the spare tire from the carrier assembly on various Toyota and Lexus
vehicles for PDI (pre-delivery inspection)
• Great time saver for PDI when selling a new vehicle or checking the air pressure of the B2193
spare tire
• Saves time when doing an oil change and the air pressure of the spare tire is checked as
part of the service
• 4ʺ long

693
• Read safety precautions on pages W1 to W4
