TIRE AND WHEEL: LUG/RETAINING NUT SOCKETS
UNDERCAR
Wheel Stud Sockets
STXL80E 1/2ʺ Drive TORX T80 Long Bit Socket Driver
®
• Bit design is longer for removing and installing wheel studs without damaging the rims
• Cold-formed socket for a strong, durable tool
• Chrome plating resists corrosion and cleans easily
• Uses STXL80E2 Replacement Bit
STXL80E

Lug Nut Sockets, 203FLSM
3/8ʺ Drive SIMML210 Lug Nut Socket
• Long socket is designed to fit lug nut
Square Drive, Overall Length,
Stock No. Wrench Size, mm applications where an extension is needed
inches inches
®
FLS2426 3/8 3/4 and 13/16 3 • Flank Drive wrenching configuration grips
FLSM1719 3/8 17 and 19 3 the fastener on the flanks/flats, increasing
the torque by up to 15-20%
FLSM2122 3/8 21 and 22 3 • Forged from tough alloy steel to increase
203FLSM 3 pc 3/8ʺ Drive Lug Nut Socket Set safety and are heat treated to a lower
• Includes FLSM1719 (17/19 mm), FLSM2122 hardness to add impact resistance
(21/22 mm) Metric Flip Lug Nut Sockets and an and ductility SIMML210
IMX31 Impact Extension • 1 pc design

Lug Nut Sockets, Wheel Lock Sockets
Magazine Loading LSR1000A Wheel Lock Removal
®
• Allows easy multiple lug nut removal LMS24 Socket Set (Blue-Point )
of up to five lug nuts at a time • Easily removes most lug nuts
• Eliminates rolling or lost lug nuts and wasted motion and wheel locks on most US and
• Ideal for use in tire and brake shops import passenger vehicles and
• Adjust type 9, 12 and 16 cu-in air chambers that are light trucks
equipped with 1/2 to 20ʺ threaded rod and 3/4ʺ nut • For use with a hand driver or
impact wrench LSR1000A
®
Square Drive, Outside Dia., Overall • Some sockets cover specific GM ,
Stock No. Wrench Size
inches inches Length, inches Ford and Chrysler applications
®
®
LMS24 3/4ʺ (19 mm) 1/2 1 5-5/16 • Set includes (11) sockets, extension and
an extractor punch in a storage case
Extensions/Snap Ring Retention, Industrial
IMX32B 1/2ʺ Drive 3ʺ Snap Ring Impact Extension
• Snap-on impact extensions are heat treated to optimize impact service life with a
®
IMX32B lower hardness and able to withstand repeated cycling loads of impact wrenches
• Snap-on uses a proprietary blend of special alloy steel that provides long life and
great strength
Torque Wrenches
BRUTUS3R300 1/2ʺ Drive Adjustable Click-Type Torque Wrench (60–300 ft-lb)
• Expanded range allows extended coverage with the 1/2ʺ drive tool servicing a majority
of vehicles and large pickup trucks
• Gives the user additional range in applying torque and angle on high-torque
BRUTUS3R300 applications
• Stamped scale (ft-lb) offers better permanency and visibility
• Features heavy-duty components; thicker diameter main tube, cam and internal
components for strength and durability
• Accuracy is ±6% CW and CCW

ISO/IZO Ratchet Head Inserts
Square Max
Drive Width, Insert Size, Recommended
Stock No. Description
inches mm mm Working Torque,
(mm) N•m
IZFRAT9X12 IZTRAT9X12 ISO/IZO Ratchet Head Inserts 1/4 (6) 37 9 x 12 25
IZFRAT9X12 ISO/IZO Ratchet Head Inserts 3/8 (10) 38 9 x 12 160
IZSRAT9X12 ISO/IZO Ratchet Head Inserts 1/2 (13) 38 9 x 12 160
IZSRAT14X18 ISO/IZO Ratchet Head Inserts 1/2 (13) 40 14 x 18 265
IZLRAT14X18 ISO/IZO Ratchet Head Inserts 3/4 (19) 40 14 x 18 960
688 IZLRAT14X18
