TIRE AND WHEEL: LUG/RETAINING NUT SOCKETS
UNDERCAR
Lug Nut Sockets
LSR1500 Standard/Twist Wheel LSR1150 1/2ʺ Square Drive SAE 3/4 and 13/16ʺ Thin
Flip Socket Set (Blue-Point ) Wall Wheel Flip Socket (Blue-Point )
®
®
• (6) sockets for use on the most popular • Thinwall wheel flip socket covers 3/4
lug nut sizes: 17 mm, 19 mm, 3/4ʺ, 21 mm, and 13/16ʺ wheel lug sizes LSR1150
13/16ʺ and 7/8ʺ • For use with a hand driver or impact wrench
• 6-point Flank Drive wrenching system at LSR1500 • 3ʺ long
®
one end and a six-fluted twist socket for LSR1250 1/2ʺ Square Drive Metric 19 and 21 mm Thin
removal of damaged wheel lugs at the other end Wall Wheel Flip Socket (Blue-Point )
®
• Socket flips when encountering a damaged head • Thinwall wheel flip socket covers 19 and
• Knurling identifies the twist socket end 21 mm wheel lug sizes
• Sockets and 3-1/2ʺ extension are all 1/2ʺ drive for • For use with a hand driver or impact wrench LSR1250
use with hand drivers or impact wrenches • 3ʺ long
• Black oxide finish
• Includes a storage case LSR1580 1/2ʺ Square Drive Metric 21 and 22 mm Thin
®
LSR2000 3 pc 1/2ʺ Square Drive Thin Wall Wheel Flip Wall Wheel Flip Socket (Blue-Point )
• Thinwall wheel flip socket covers 21 and
®
Socket Set (Blue-Point ) 22 mm wheel lug sizes
• Covers the four most popular lug nut • For use with a hand driver or impact wrench LSR1580
sizes: 3/4 and 13/16ʺ, 19 and 21 mm • Requires the use of optional LSR1000EXT extension
®
• Flank Drive wrenching configuration • 3ʺ long
• 1/2ʺ square drive is located at the LSR2000 ®
center of the socket LSR1560 Flip Socket (Blue-Point )
• For use with a hand driver or impact wrench • 7/8ʺ and 1ʺ socket size: 3ʺ long
• Includes (2) lug nut sockets and a 3-1/2ʺ extension • For use with a hand driver or impact wrench
• Black industrial finish • Expands LSR2000 and LSR2000PLUS sets LSR1560
• Includes a storage case • Requires use of the LSR1000EXT extension
(not included)
LSR2000PLUS 3 pc 1/2ʺ Square Drive Lug Nut Flip • 1/2ʺ square drive is located at the center of the socket
®
Socket Set (Blue-Point ) • Applications: (7/8ʺ) Chevy , GMC vans, Dodge Ram
®
®
®
®
• Includes (3) lug nut flip sockets: 1500, Ford E-250/E-350, Ford Super-Duty, Hummer
®
®
®
3/4 and 13/16ʺ, 7/8 and 15/16ʺ and H1, Lincoln Blackwood , Lexus LX470, Toyota Land
®
®
®
®
19 and 21 mm Cruiser, Jaguar XJ Series, (7/8 and 1ʺ) Chevy /GMC
®
®
®
• All sockets are 3ʺ long LSR2000PLUS pickups and SUVs, (1ʺ) Plymouth 1 ton vans
®
• 1/2ʺ square drive is located at the center of the socket LSR1570 Flip Socket (Blue-Point )
®
• Use with a hand driver or impact wrench • 15/16 and 1-1/16ʺ socket size: 3ʺ long
• Includes a storage case • For use with a hand driver or impact wrench
• Black industrial finish on all components • Expands LSR2000 and LSR2000PLUS sets
• Requires the use of optional LSR1000EXT extension • Requires use of the LSR1000EXT extension LSR1570
(not included) (not included)
LSR2500 Lug/Lock Flip Twist Socket Set (Blue-Point ) • 1/2ʺ square drive is located at the center of the socket
®
• Quickly and easily remove damaged • Applications: (15/16ʺ) Dodge Ram 2500, 3500, (1-
®
®
wheel lugs (six-flute end) or damaged 1/16ʺ) Land Rover , Range Rover Discovery II, Ford
®
®
®
wheel locks with damaged or lost E-300/E-350, Ford F-300/F-350
®
keys (12-flute end) LSR1450 Thin Wall Wheel Flip Socket (Blue-Point )
®
• 1/2ʺ square drive is located at the • Covers 17 and 19 mm wheel lug sizes
center of the socket LSR2500 • Flank Drive wrenching configuration
®
• Used with a hand driver or impact wrench • 1/2ʺ square drive is located at the center
• Includes LSR2501 and LSR2502 lug/lock sockets of the socket (requires optional extension
and a 3-1/2ʺ extension in a custom case LSR1000EXT) LSR1450
• Black industrial finish • Ideal companion to the LSR2000 and LSR2000PLUS
LSR2500PLUS 3 pc 1/2ʺ Square Drive Lug/Lock Flip • Black industrial finish
®
Twist Socket Set (Blue-Point ) • Major O.D.: 1.03ʺ (26.3 mm)
• Quickly and easily remove damaged • Minor O.D.: 0.94ʺ (23.9 mm)
wheel lugs (six-flute end) or damaged • Length: 3ʺ (76.2 mm)
wheel locks with damaged or lost keys LSR2501 Lug/Lock Flip Twist Socket (Blue-Point )
®
(12-flute end) • 3/4ʺ (19 mm) twist socket quickly and easily
• 1/2ʺ square drive is located at the center LSR2500PLUS removes damaged wheel lugs (six-flute end)
of the socket or damaged wheel locks with damaged or
• Uses with hand driver or impact wrench lost keys (12-flute end)
• Includes (3) lug/lock sockets • For use with a hand driver or impact wrench LSR2501
• Black industrial finish • Black industrial finish
• LSR1000EXT is an optional 3ʺ extension for the set • 2-5/8ʺ overall length
• Includes a storage case LSR2502 Lug/Lock Flip Twist Socket
®
LSRM2000 Metric Flip Socket Set (Blue-Point ) (Blue-Point )
®
• Includes LSR1580 and LSR1450 sockets plus the • Same as LSR2501 except in 7/8ʺ size
LSR1000-EXT 3ʺ extension LSR2502
• Designed for 2005—later vehicles LSR2503 Lug/Lock Flip Twist Socket
®
• Includes 17 mm, 19 mm, 21 mm and (Blue-Point )
22 mm sizes • Same as LSR2501 except in 17 mm size
®
®
®
• Applications: Dodge RAM 1500, Dodge LSRM2000
®
®
®
SRT-10, Honda Odyssey , Land Rover LSR2503
®
®
L3, Range Rover and Sport, Lexus LX470
686 and Toyota Land Cruiser vehicles
®
®
