WHEEL ALIGNMENT: TIE ROD
UNDERCAR

YA3000D WA14A WA800 ITRS22

Tie Rod Removal/Installation Tools
YA3000D Inner Tie Rod Tool WA15 Tie Rod End Socket ITRS22 Tie Rod Bushing Socket
®
(Blue-Point ) • Similar to WA14A • Used to access the inner tie rod
®
®
• Removable crowfoot adaptors are • For tie rod servicing on most trucks bushings on Chrysler LHS /
®
placed on the hex of tie rod in the Class 2–6 range Concorde and Dodge 300M/
®
• Engages the crowfoot for removal or • U-shaped opening measures Intrepid featuring the LH
installation of the tie rod 1-7/8 x 15/16ʺ body style
• Includes crowfoot adaptors in • For use with 1/2ʺ square drive • Low-profile design provides easy
1-3/16, 1-1/4, 1-5/16, 1-7/16, 1-1/2ʺ handles access to remove or install the
and 33.6 mm sizes • 2-1/2ʺ ID, 2-7/8ʺ long 7/8ʺ or 22 mm hex head bolts that
WA14A Tie Rod End Socket WA800 Heavy-Duty Truck Tie Rod attach the inner tie rod bushing to
®
• For removing tie rod ends Socket (Blue-Point ) the rack-and-pinion assembly
• U-shaped opening measures • For use on most Class 7 and 8 • A conventional socket cannot be
1-3/8 x 3/4ʺ heavy-duty trucks with 9 used in this application
• For use with 1/2ʺ square drive ,000–20,000 lb axles
handles • U-shaped slot measures
• 1-15/16ʺ I.D.; 2-1/4ʺ long 1-7/8 x 1-1/2ʺ
• Fits most cars and some trucks • 3ʺ inside dia.; 3-1/2ʺ overall length
STRUT

MacPherson/Coil Spring Compressors
WA92 Coil Spring Compressor
• Holds the coil spring at the desired tension for removal
of other parts
• 11ʺ screw
• Liberally lubricate threads with anti seize compound
MSC1 ‡ Master MacPherson Strut Tool (Blue-Point )
®
• Designed to quickly and easily compress most
MacPherson strut springs
• Compresses up to 5/8ʺ coil diameter
WA92 • Broad spring contact for stable compression
• ACME threaded rod and built-in detent latches to help
lock the coil in place
• Forged construction for strength and durability
®
MSC2 ‡ Coil Spring Compressor (Blue-Point )
• Removes and installs coil springs quickly and safely
• Compresses coil springs on all passenger cars and
pickup trucks
• Features an ACME threaded rod
• Includes an instructional card
MSC2 MSCS1000 ‡ Master Spring Compressor Set
®
(Blue-Point )
• Includes MSC1 and MSC2 in a storage case

Strut Tools
®
WA7500 Strut Cartridge Tool for GM Vehicles
®
(Blue-Point )
• Replaces strut cartridge through the body shock tower
on GM 10 Series (W Car) vehicles
®
WA7500 • Applications include 1988–later Pontiac Grand Prix ;
®
®
Oldsmobile Cutlass; Buick Regal ; 1989–later
®
®
®
®
Chevrolet Lumina
