WHEEL/AXLE PULLERS AND DRIVE LINE
UNDERCAR

Wheel Hub Removal Adaptors
®
DHP1 Wheel Hub Removal Adaptor for Dodge Vehicles
• Designed to remove the front hubs found on 3/4-ton (2500 Series) and 1-ton (3500
®
Series) Dodge pickup trucks
• Cuts the flat rate for changing out U-joints, front differential service, ball joints and
any front hub service
• On average it takes 3.4 hours to do both sides using a sledge hammer, torch or heavy-
duty slide hammer—with the DHP1, it takes about one hour to do both sides
DHP1 • No broken rotors when using a sledge hammer
• No heavy slide hammers to use
• Wheel bearing and seal will not get damaged when using a torch on a stuck hub
FHP1 Wheel Hub Removal Adaptor for Ford Vehicles
®
®
®
®
®
• Designed to take off the front hubs found on the Ford F-250 /F-350 series Ford
pickup trucks
FHP1 • Cuts the flat rate for changing out U-joints, front differential service, ball joints and
any front hub service
• Soft insert of the socket will not damage the studs

Wheel/Axle Hub Pullers
®
CJ129A ‡ Universal Wheel Hub Puller (Blue-Point )
®
• Removes the front wheel/axle assembly on all front wheel drive Ford , GM , Chrysler
®
®
CJ129A and most imported cars
• Also used to remove the rear brake drums on tapered axles, such as those found on
AMC and Chrysler vehicles
®
®
• Removable anvil fits over a 1-1/8ʺ hex on the pressure screw
• Includes adjustable legs
YA498A Front Wheel Drive Hub Puller (Blue-Point )
®
• For most US and import vehicles with independent front suspension
• 5/8ʺ-18 x 5-1/2ʺ pressure screw size
YA498A

Slide Hammers and Shafts
®
CJ1250 Slide Hammer, 12 lb, 5/8ʺ-18 Thread (Blue-Point )
CJ1250 • Designed to pull rear axles
• Slide hammer is approximately 25-1/4ʺ long with a 5/8ʺ-18 thread
• Can be used with the YA498A Hub Puller
CJ1300 Heavy-Duty Hub/Rotor Puller (Blue-Point )
®
• Heavy-duty 1ʺ shaft is designed for tough pulling jobs such as hubs, rotors and axles
• Slide hammer is approximately 28-1/2ʺ long with a 5/8-18 threaded hex bolt, which
allows the end user to bolt the pulling adaptors to the end of the shaft, locking it in
place and taking much of the stress off the threads
• 10 lb hammer
CJ1300

702

Snapon.com 1.877.762.7664
