DRIVE LINE: TRANSMISSION

YA2340 YA7244A FIH9057B LDT3812

S5902 UNDERCAR
LDTM3812
XLE1012A SLEPL200
Transmission Service Tools
®
®
YA2340 Sealing Cap Set (Blue-Point ) LDTM3812 Camshaft Seal Kit (Blue-Point )
• Retains transmission fluid by sealing the transmission • Easily removes and installs camshaft and crankshaft
and transaxles when the drive shaft or drive axle is seals without damage
removed on most US and import vehicles • Compact puller with unique extracting hooks engages
®
• Side gear centering for Ford transaxles seal for quick removal
• Five caps cover a range of 1–2-3/16ʺ (25.4–55.37 mm) • Interchangeable sleeves and mandrels allow easy
• Segmented design prevents caps from slipping installation of the new seal
YA7244A Quick-Connect/Disconnect Tool • Fits seals 21.5–64 mm
• For late-model Ford vehicles using push lock connectors S5902 Oil/Transmission Plug Box End 17 mm, 6-Point,
®
on transmission cooler lines, as well as on fuel lines 21 mm, 12-Point Wrench
• 1-1/4ʺ dia • Box ends are 17 mm, 6-point and 21 mm, 12-point
FIH9057B Transmission Line Quick-Disconnect Tool • Designed for VW transmission drain plugs
®
• For 3/8ʺ O.D. and 1/2ʺ O.D. transmission and fuel lines on • 258 mm long
certain Ford and Cadillac models XLE1012A E10–E12 TORX Standard 10º Offset
®
®
®
• Constructed from a durable 30% glass-filled nylon allows Box Wrench
more pressure to be applied and delivers a longer tool life • Box end TORX sizes are E10 and E12
®
than plastic units • Drive shaft must be removed when towing 1980
• Compact design allows access in tight quarters Chevrolet Corvette and 1/2-, 3/4- and 1-ton GMC and
®
®
®
FOS1 Transmission Output Shift Socket Chevrolet trucks
®
• Four pin socket designed to remove the transmission • Designed to access drive line fasteners
®
output shaft retaining nut on Ford 5R100 automatic • Also services AMC drive lines
®
transmissions SLEPL200 1/2ʺ Drive 20EPL TORX Plus with
®
• Tool needed when doing transmission service such as
removing and replacing transmission seals Countersink Socket ®
• Manufactured from special alloy steel • SLEPL Series of TORX Plus sockets with a shallow ®
• Precision machined and heat treated for optimum countersink are designed for use on external TORX Plus
strength and durability low-profile head fasteners so the user can fully engage
the fastener head
LDT3812 Transmission Oil Cooler Line Disconnect Tool • For removal and installation of low-profile drive plate and
®
(Blue-Point ) flywheel bolts on QR25 Nissan motors with automatic
®
• Two sizes (3/8 and 1/2ʺ) are designed to disconnect transmissions
transmission cooler lines • Similar to the J-45816 Nissan specialty tool
®
®
• 3/8ʺ for use on 2003–later Ford V8 Explorer, 2004–later • For flywheel bolts on Nissan QR25 motors with manual
®
Ford F-150 and Cadillac vehicles transmissions use the FTX50TPE 3/8ʺ Drive T50 TORX
®
®
®
• 1/2ʺ for use on Ford F-250/F-350/F-450 Super-Duty trucks Plus Male Socket
®
Pressure Gauge Sets
EEPV508 ‡ Automatic Transmission and Engine Pressure Set
• Includes (2) gauge assemblies for high-pressure (500 PSI) and
low-pressure (100 PSI) ranges, adaptors to test a wide variety of
automatic transmissions, a comprehensive instruction manual with
an applications table and a storage case
• (4) special fittings are also included for connection to hard-to-reach
test ports in areas requiring a 45° or 90° angle
• High-pressure gauge assembly includes a 3.5ʺ dia. gauge
• 10ʹ flexible hose with fluid coupler
• 6ʹ flexible hose with fluid coupler
• Technical Support: 1-855-779-8880
EEPV508
• Do not use chrome or industrial finish hand tools with impact driver
• Do not use “cheater bars” on handles 705
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
