STRUT

Strut Sockets
SSV1 2 pc 1/2ʺ Drive Strut Socket Kit
®
• Used to remove and install strut nuts on various Volvo models
• Manufactured from special steel with a higher alloy content
• Industrial finish helps protect against corrosion
• Precision machined and heat treated for optimum strength and durability
• Includes SSV1-1 and SSV1-2 Strut Sockets
®
SSV1-1 1/2ʺ Drive Volvo Strut Socket SSV1
®
• For uyse with SSV1-2 to remove and install strut nuts on various Volvo models UNDERCAR
®
SSV1-2 1ʺ Hex Drive Volvo Strut Socket
• For use with SSV1-1 to remove and install strut nuts on various Volvo models
®
WHEEL/AXLE PULLERS: KING PIN PULLERS

CG430HYC
20-Ton Capacity Hydraulic
Pressure Screw Work Head Yoke Post (2) Pilot Guide 1-3/8ʺ x 7/8ʺ Expansion Plug Hydraulic 7/8ʺ Diameter
Stock No.
Bushing Power Pack Pilots
CG430HYC CG430-1 CG430-3 CG430-4 CG430-6 CG430-7 CJ91-2A CG420A CG230-9 (6ʺ)
— — — — — — — — CG230-8 (4ʺ)
— — — — — — — — CG230-10 (8ʺ)
CG430HYC Hydraulic King Pin Press Set
• CG420A hydraulic ram and pump delivers up to 20-tons of controlled power to remove
stubborn king pins on large vehicles with king pin diameters up to 1-1/4ʺ
• Also removes brake shoe anchor pins on trucks
• Wide side arm construction
• Uses three pilots: 7/8 x 4ʺ, 7/8 x 6ʺ and 7/8 x 8ʺ
• Includes two guide bushings: 1-3/8 x 7/8ʺ and 1-3/8 x 3-1/4ʺ

35-Ton Capacity Hydraulic
Pressure Yoke Adaptor Work Head Yoke Post Pilot Guide Post Nut (2) 1-9/16ʺ Hydraulic Pilots
Stock No.
Screw (2) Bushing Power Pack
CG730HY CG730-1 CG730-2 CG730-3 CG730-4 CG730-6 CG750-7 CG730-8 CG420A —
— — — — — — — — — CG730-10 (2-1/4ʺ)
— — — — — — — — — CG730-11 (4-1/2ʺ)
— — — — — — — — — CG730-13 (9ʺ)
CG730HY Hydraulic King Pin Press
• For use on large trucks and semi trucks with king pin diameters from 1–2ʺ
• Similar to CG430HYC except it uses 35-ton hydraulic power components (CG720 ram, CG420-2A
pump, CG420-3-1 hose and CG420-4 quick coupler)
• Includes (3) guide bushings and (7) pilots
CG730 Manual King Pin Press Set
• Same as the CG730HY Set, less the hydraulic power components

• Do not use chrome or industrial finish hand tools with impact drivers 701
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
