MarSurf CM expert

3D Surface Measurement

DESCRIPTION

• Automatable, high-end
measuring system
• The MarSurf CM expert is a
powerful confocal microscope
for the three-dimensional mea-
surement and analysis of sur-
faces – contactless, indepen-
dent of material, and fast.
• The MarSurf CM expert is suit-
able for use in test laboratories
and equipped for quality assur-
ance in production environments
due to its robust construction
and insensitivity to environmen-
tal influences.
• With additional manual Z posi-
tioning, a large x and y travel
range and the possibility of au-
tomation, it offers excellent ease
of use. The option of performing TECHNICAL DATA
user-independent, fully auto-
matic measurements makes this CM expert
surface measuring system ideal Measuring principle Confocal
for straightforward and efficient High-performance LED (505nm / white)
use in quality assurance.
Key benefits: Supplied with: MarSurf CM expert APPLICATIONS
• User-independent serial • Confocal measuring head
mea surements by automation – HDR camera (B/W or color camera) Mechanical Engineering
software – 4x lens revolver with identification • To qualify and quantify roughness, geometry and
• High measuring speed – • L-tripod including control electronics wear volume
even at full resolution • Motorized XY table (100x100 mm) with glass
• User-friendly concept scales for sample positioning and image field Electronics and semiconductors
• Safety through collision merging (“stitching”) • Component inspection down to the sub-
detec tion in all directions to • Motorized Z-axis (70 mm) with glass micrometer range for defect-free products
protect your workpiece and measuring scale
measuring system • Measuring system computer with 24” TFT monitor Medical Technology
• High Dynamic Range (HDR) • Objective lenses: • Quality assurance of medical surfaces in
function, 16-bit – 5x to 100x selectable production and laboratory
• Consistent high resolution out- • MarSurf MSW for intuitive data acquisition
put of large measuring surfaces • MarSurf ASW for automation (optional) Material Science
due to HD stitching • MarSurf MfM for professional evaluation, • Optimization of functional properties
• This established optical graphical representation and creation of of new surfaces and products
measuring system is success- measuring records (choice of Standard, Extended
fully used, for example, for: or Premium version) Microsystems Technology
• Roughness measurement • Measure complex surface geometries of smallest
according to components with nanometer precision
DIN EN ISO 4287 / 25178
• Topography measurement
(including volume, wear, isotropy)
• Measurement of microgeometry
and layer thicknesses
• Users value the reliability of this
measuring system, which pro-
vides quantitative, traceable
• 3D characteristics for many
industries.

For more information, please visit our website: www.mahr.com

548 MarSurf | Surface Measuring Instruments
