MarSurf CM mobile

3D Surface Measurement

DESCRIPTION

• Ready for use anywhere
• The compact MarSurf CM
mobile is a portable confocal
microscope for the three dimen-
sional measurement and analysis
of surfaces – non-tactile, inde-
pendent of material and fast.
• Its low weight and operation via
a laptop allow for flexible use
when measuring on large objects
and difficult to move workpieces,
such as rollers.

• Mobile application enables test-
ing directly on the component /
tool – even if they are only briefly
accessible
• Compact system (5 kg) with
motorized axes for HD stitching
• Robust and reliable for use in TECHNICAL DATA
production
• High measuring speed – CM mobile
even at full resolution Measuring principle Confocal
• User-friendly concept High-performance LED (505 nm)
• Consistently high resolution even
with large measurement areas
thanks to HD stitching Supplied with: MarSurf CM mobile APPLICATIONS
• The established optical • Confocal measuring head
measuring system is success- – B/W camera Mechanical Engineering
fully used, for example for: – 4x lens revolver • To qualify and quantify roughness, geometry
• Roughness measurement • Control electronics integrated in the system and wear volume
according to • Motorized XY table (50x50 mm) with glass scales
DIN EN ISO 4287 / 25178 for positioning and image field merging Electronics and semiconductors
• Topography measurement (“stitching”) • Component inspection down to the
(including volume, wear, isotropy) • Motorized Z-axis (35 mm) sub-micrometer range for defect-free products
• Measurement of microgeometry • Laptop or measuring system computer
and layer thicknesses with 24” TFT monitor selectable Medical Technology
• Users value the MarSurf CM • Objective lenses: • Quality assurance of medical surfaces in
mobile as a reliable measuring – 5x to 100x selectable production and laboratory
system that provides quantitative • MarSurf MSW for intuitive data acquisition
traceable 3D characteristics for • MarSurf for professional evaluation, graphical Material Science
many industries. representation and creation of measuring records • Optimization of functional properties of
(choice of Standard, Extended or Premium version) new surfaces and products

Microsystems Technology
• Measure complex surface geometries of smallest
components with nanometer precision

MarSurf | Surface Measuring Instruments 549
