MarSurf CM explorer

3D Surface Measurement

DESCRIPTION

• The flexible, all-round
measuring solution
• The MarSurf CM explorer is a
compact confocal microscope for
the three-dimensional measure-
ment and analysis of surfaces
– contactless, independent of
material, and fast.
• The MarSurf CM explorer is
suitable for use in test lab-
oratories and equipped for
quality assurance in production
environments due to its robust
construction and insensitivity to
environmental influences.

Key benefits:
• High measuring speed –
even at full resolution
• User-friendly concept TECHNICAL DATA
• Safety through collision detec-
tion in all directions to protect CM explorer
your workpiece and measuring Measuring principle Confocal
system High-performance LED (505 nm / white)
• High Dynamic Range (HDR)
function, 16-bit
• Consistent high resolution Supplied with: MarSurf CM explorer APPLICATIONS
output of large measuring • Confocal measuring head
surfaces due to HD stitching – HDR camera (B/W or color camera) Mechanical Engineering
• This established optical – 4x lens revolver with identification • To qualify and quantify roughness,
measuring system is success- • L-tripod including control electronics geometry and wear volume
fully used, for example, for: • Motorized XY table (50x50 mm) with glass scales
• Roughness measurement for sample positioning and image field merging Electronics and semiconductors
according to (“stitching”) • Component inspection down to the
DIN EN ISO 4287 / 25178 • Motorized Z-axis (70 mm) with glass sub-micrometer range for defect-free products
• Topography measurement measuring scale
(including volume, wear, • Measuring system computer with 24” TFT monitor Medical Technology
isotropy) • Objective lenses: • Quality assurance of medical surfaces
• Measurement of microgeometry – 5x to 100x selectable in production and laboratory
and layer thicknesses • MarSurf MSW for intuitive data acquisition
• Users value the MarSurf CM • MarSurf MfM for professional evaluation, Material Science
explorer as a reliable measuring graphical representation and creation of • Optimization of functional properties
system that provides quantitative measuring records (choice of Standard, Extended of new surfaces and products
traceable 3D characteristics for or Premium version)
many industries. Microsystems Technology
• Measure complex surface geometries of smallest
components with nanometer precision

For more information, please visit our website: www.mahr.com
