MarSurf CM select

3D Surface Measurement

DESCRIPTION

• Tailor-made measurement of
surfaces
• The MarSurf CM select is a
powerful, configurable confocal
microscope for the three-dimen-
sional measurement and analysis
of surfaces – contactless, inde-
pendent of material, and fast.
• Axes and isolation systems as
well as software modules can
be combined individually. This
allows the measuring system to
be adapted to different measur-
ing tasks.
• As a multi-sensor system, the
MarSurf CM select also offers
the possibility of combining
different sensor technologies in
one measuring device. Depend-
ing on the measuring task, the TECHNICAL DATA
optimal point sensor can also be
flexibly selected. CM select
• The MarSurf CM select meets Measuring principle Confocal
your individual requirements for High-performance LED (505 nm / white)
automation, measuring comfort
and accuracy – right up to the
fully automated measuring Supplied with: MarSurf CM select APPLICATIONS
solution. • Confocal measuring head
– HDR camera (B/W or color camera) Mechanical Engineering
Key benefits: – 4x lens revolver with identification (optional) • To qualify and quantify roughness, geometry
• Designed for continuous • Gantry design including control electronics and wear volume
operation • Motorized XYZ axes available in different variants
• Automation software with • Industrial computer including two 24” TFT Electronics and semiconductors
industrial interfaces for transfer monitors • Component inspection down to the sub-
to QA systems • Objective lenses: micrometer range for defect-free products
• High measuring speed – – 5x to 100x selectable
even at full resolution • Vibration damping system available Medical Technology
• Individually configurable to • Multi-sensor system (optional) • Quality assurance of medical surfaces in
your sample size • Overview camera (optional) production and laboratory
• Multi-sensor system • MarSurf MSW for intuitive data acquisition
• User-friendly concept • MarSurf ASW for automation (optional) Material Science
• Safety through collision detec- • MarSurf MfM for professional evaluation, • Optimization of functional properties of new
tion in all directions to protect graphical representation and creation of surfaces and products
your workpiece and measuring measuring records (choice of Standard, Extended
system or Premium version) Microsystems Technology
• High Dynamic Range (HDR) • Measure complex surface geometries of smallest
function, 16-bit components with nanometer precision
• Consistent high resolution out-
put of large measuring surfaces
due to HD stitching
• This established optical
measuring system is success-
fully used, for example, for:
• Roughness measurement
according to
DIN EN ISO 4287 / 25178
• Topography measurement
(including volume, wear, isotropy)
• Measurement of microgeometry
and layer thicknesses
• Users value the reliability of this
measuring system, which
provides quantitative, traceable
3D characteristics for many
industries.

550 MarSurf | Surface Measuring Instruments
